Dust Proof SAW Touch Screen , 17 Inch Touch Panel For Indoor Outdoor
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Light Transmission | 100% Without Glass | Operate System Support | Windows®7,Windows®8,Vista,XP,Mac® OS,Linux,Android |
|---|---|---|---|
| Number Of Touch Points | 1 Touch Points | Operating Environment | Indoor And Outdoor |
| Outside Dimensions | 389±1.5mm(L)×321±1mm(W)×8.8±0.5mm(H) | Active Area | 340±1mm(L)×272±1mm(W) |
| Housing | Aluminum | Product Name | SAW Touch Screen |
| High Light | Dust Proof SAW Touch Screen,17 Inch SAW Touch Screen,Outdoor 17 Inch Touch Panel | ||
Product Description
17 Inch SAW Touch Screen Panel Dust Proof Kiosk Indoor Outdoor
SAW Touch Screen Main Features
KeeTouch SAW touch technology, accurate touch, free of drift
Fast response time 5-10ms, The SAW Touch Screen has perfect touch experience
With tempered glass, vandal proof and dust proof
With aluminum frame, dust proof is available
the SAW Touch screen has 90% high transparency, superior image clarity
Activated by finger, gloved hand, leather or soft stylus
USB and RS232 interfaces, support Windows7, Windows8, Vista, XP, Mac, Linux, Android
Other sizes are available (7’’- 43’’)
SAW Touch Screen Specifications
Size | 17 inch |
Housing | Aluminum |
Dimensions | 389±1.5mm(L)×321±1mm(W)×8.8±0.5mm(H) |
Active Area | 340±1mm(L)×272±1mm(W) |
Aspect Ratio | 5:4 |
Touch Activation Force | No minimum touch pressure required |
Number of touch points | 1 touch points |
Driver free | HID* compatible |
Linearity Deviation | ±1mm |
Response Time | 5-10ms |
Operate System Support | Windows®7,Windows®8,Vista,XP,Mac® OS,Linux,Android |
Temperature | operating：-20oC ~ 70o C |
storage：-40oC ~ 85oC | |
Humidity | operating：10% ~ 90% |
storage： 10% ~ 90% | |
Certifications | FCC , CE, RoHS |
Operating Environment | Indoor and outdoor |
Applicative Screen | LED、LCD、PDP etc. |
Applications
Widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer founded in 2006, located in Shenzhen, China.
2. What's your MOQ for the SAW Touch Screen?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the SAW Touch Screen?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Can you produce for the SAW Touch Screen according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are offered.
5. What is your payment method?
We can accept T/T, Western Union, Paypal,Credit card and Alipay. ( L/C can be negotiable. )
6. What is your delivery time for the SAW Touch Screen?
3-5 work days for inventory orders, 7-15 business days for bulk production.
