22 Inch SAW Touch Monitor 16:10 Ratio 1680x1050 For ATM Kiosks

22 Inch SAW Touch Monitor 16:10 Ratio 1680x1050 For ATM Kiosks
22 Inch SAW Touch Monitor 16:10 Ratio 1680x1050 For ATM Kiosks 22 Inch SAW Touch Monitor 16:10 Ratio 1680x1050 For ATM Kiosks 22 Inch SAW Touch Monitor 16:10 Ratio 1680x1050 For ATM Kiosks 22 Inch SAW Touch Monitor 16:10 Ratio 1680x1050 For ATM Kiosks 22 Inch SAW Touch Monitor 16:10 Ratio 1680x1050 For ATM Kiosks
Place of Origin Shenzhen，China
Brand Name KeeTouch
Certification CCC, UL, FCC, CE, CB, RoHS
Model Number KOT-220P-014(KOT-0220US-SA6BP)
Minimum Order Quantity 1 piece
Price Negotiable
Packaging Details carton box
Delivery Time 7-15 work days
Payment Terms L/C, T/T, Western Union
Supply Ability 1000 Pieces per Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Display Type 16:10 Ratio 22" TFT-LCD Display Active Area 376.32*301.06 (mm)
RespoSuggested Resolutionnse Time(Typ.) 1680*1050@ 60Hz Video Input VGA/DVI
Storage Temp. -20～60°C Support Colors 10%～90%
Response Time ≤8ms(USB) ; ≤12ms(RS232) Product Name SAW Touch Monitor
High Light

22Inch ATM SAW Touch Monitor

,

Kiosks SAW Touch Monitor

,

1680x1050 22 inch touch monitor
Leave a Message
Product Description

22 Inch SAW Touch Monitor 16:10 Ratio 1680x1050 For ATM Kiosks



SAW Touch Monitor Main Features:

  • KeeTouch SAW touch panel, accurate touch and fast response

  • High-quality, dust-proof SAW touch monitor, durable in harsh environment

  • High resolution, high contrast, superior quality image with wide viewing angle

  • Multiple mounting options include VESA mount, horizontal or vertical brackets mount

  • VGA+DVI interfaces,USB/RS232 for touch input

  • Support systems: XP,WIN7,WIN8,WIN10, Linux, Android

  • Other sizes are available (7’’- 43’’)



SAW Touch Monitor Specifications



Complete Machine
Model No. KOT-0220US-SA6BP (P/N:KOT-220P-014)
Series OT
Display Type 16:10 Ratio 22" TFT-LCD
Active Area 376.32*301.06 (mm)
Monitor Dimensions (W*H*D) 473.8 mm×296.1 mm
Suggested Resolution 1680*1050@ 60Hz
Support Colors 16.7M
Brightness (Typ.) Pure LCD Panel 250cd/m2
With Touch Monitor 225cd/m2
Response Time (Typ.) 5ms
Viewing Angle(Typ.at CR＞10)) Horizontal(left/right) 85°/85°
Vertical(up/down) 80°/80°
Contrast Ratio (Typ.) 1000:1
Video Input VGA/DVI
Video Input connector Mini D-Sub 15-pin VGA and DVI-D
Frequency (H/V) 30 -80KHz/ 60～75Hz
Power Supply

Type: External brick

Display voltage: DC 12V±5%

Input (line) voltage: 100-240 VAC, 50-60 Hz
Environment Operating Temp. 0～50°C
Operating RH 20%～80%
Storage Temp. -20～60°C
Storage RH 10%～90%
MTBF ≥30,000 Hours
LED Back Light Life (Typ.) ≥30,000 Hours
Weight(N.W/G.W) 7.4Kg(1pcs)/20.8Kg(2pcs in one package)
Package dimensions 635*190*435(mm)(2pcs in one package)
Power Consumption Standby Power: ≤1.5W / Operating Power: ≤30W
Mount Interface

1.VESA 75mm and 100mm

2.Mount bracket, horizontal or vertical mount
OSD Control Buttons AUTO,+,POWER,-,MENU
Function Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Touch Screen Type 22" Surface acoustic wave touch screen(6mm)
Touch input USB/RS232
Agency approvals CCC, ETL, FCC, CE, CB, RoHS
Regular Warranty 1 year






SAW Touch Monitor Mechanical Dimensions





22 Inch SAW Touch Monitor 16:10 Ratio 1680x1050 For ATM Kiosks 0





Applications





Widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.



22 Inch SAW Touch Monitor 16:10 Ratio 1680x1050 For ATM Kiosks 1



FAQ



1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.



2. What’s your MOQ for SAW touch monitor?

Our minimum order quantity is 1pc only.



3. What is your warranty period for SAW touch monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).



4. Can you produce the product according to the customer's requirements?

Sure, with 40+ Professional R & D engineers, OEM and ODM are offered.



5. What is your payment method?

We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )



6. What is your delivery time for SAW touch monitor?

3-5 work days for inventory orders, 7-15 business days for bulk production.
