17 Inch SAW Touch Monitor 1280x1024 Resolution For Kiosks
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Display Type | 5:4 Ratio 17＂Active Matrix TFT-LCD, LED Backlight | Display Active Area | 13.3＂(338mm)×10.6＂(270mm) |
|---|---|---|---|
| Power Consumption | 16W Max | MTBF | 30,000 Hours |
| Response Time(Typ.) | 5s | Video Input | VGA/DVI |
| Touch Response Time | USB/ 8.4ms | Product Name | SAW Touch Monitor |
| High Light | SAW Touch Monitor 1280x1024,17Inch Kiosks Touch Monitor,Dustproof SAW Touch Monitor | ||
Product Description
17 Inch SAW Touch Monitor 1280x1024 Resolution for Kiosks
This 17 inch SAW touch monitor comes with the main features as below: IP65 waterproof, dust-proof and vandal-proof, 5:4 ratio, 1280*1024 resolution, 1000:1 contrast ratio. This industrial grade SAW touch monitor are matched with . And VGA interface are provided for use, USB port for touch. Also, we attach great importance to our product quality, and all our products are approved by global certifications, such as FCC, CE, RoHS, UL, etc.
Specifications of SAW Touch Monitor
Model No. | KOT-0170U-SA4BCW（P/N:KOT-170C-009） | |||
Series | ||||
Display Type | 5:4 Ratio 17＂Active matrix TFT-LCD, LED backlight | |||
Display Active Area | 13.3＂(338mm)×10.6＂(270mm) | |||
Touch Monitor Dimensions | Width: 369mm Width with brackets: 389.4 mm Height: 307mm Height with brackets: 327.4mm Depth: 49mm(not include lip):50mm(include lip) | |||
Suggested Resolution | 1280×1024@60Hz | |||
Support Colors | 16.7M | |||
Brightness(Typ.) | Pure LCD Panel | 250cd/m2 | ||
With SAW Glass | 225cd/m2 | |||
Response Time(Typ.) | 5ms | |||
Viewing Angle (Typ.at CR＞10)） | Horizontal(left/right)： 170°（85°/85°） | |||
Vertical(up/down)： 160°（80°/80°） | ||||
1000:1 | ||||
Video Input | Analog RGB | |||
Frequency（H/V） | 30～80KHz / 60～75Hz | |||
Power Supply | Type: External brick Input (line) voltage: 100-240 VAC, 50-60 Hz | |||
Environment | Operation Temp: | 0～50°C | ||
Storage Temp: | -20～60°C | |||
Operation RH: | 20%～80% | |||
Storage RH: | 10%～90% | |||
30,000 Hours | ||||
LED Back light Life(Typ.) | 30,000 Hours | |||
Weight（N.W/G.W） | N.W :5Kg (Single) /G.W:12.8Kg (2pcs in one package) | |||
Package Dimensions | 445（L）*200(W)*395(H)mm（2pcs in one package） | |||
Power Consumption | 16W Max. | |||
Standby power consumption | 0.95W | |||
Mount Interface | 1)VESA 75mm and 100mm 2)Mount bracket, horizontal or vertical(Standard mount brackets are supplied) | |||
OSD Control | Buttons | AUTO,+,POWER,-,MENU | ||
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |||
Touch screen Type | Keetouch 17" SAW 4 mm compact touch sensor | |||
Touch System Interface | Having USB interface | |||
Touch Response time | USB/ 8.4ms | |||
Agency Approval | CCC, ETL, FCC, CE, CB, RoHS | |||
Regular Warranty | 1 year | |||
Applications
Retail
Gaming
Kiosk
self-service
Finance
Transit
Conference
Education
Healthcare
public service
e-commerce
Hotels
restaurants
Advantages of SAW Touch Monitor
1. High Clarity: SAW touch screens maintain high clarity and contrast levels, even when viewed from different angles or under varying lighting conditions, providing a clear and vibrant display.
2. High Sensitivity: SAW touch screens are highly sensitive and can detect even the slightest touch or gesture, providing a responsive and accurate user experience.
3. Durability: SAW touch screens are highly durable and can withstand heavy usage, making them ideal for use in public places such as retail stores, museums, and airports.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
2. What’s your MOQ for the SAW Touch Monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the SAW Touch Monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
