CCC Approved 15 Inch SAW Open Frame Touch Monitor IP65 Waterproof

CCC Approved 15 Inch SAW Open Frame Touch Monitor IP65 Waterproof
CCC Approved 15 Inch SAW Open Frame Touch Monitor IP65 Waterproof CCC Approved 15 Inch SAW Open Frame Touch Monitor IP65 Waterproof CCC Approved 15 Inch SAW Open Frame Touch Monitor IP65 Waterproof CCC Approved 15 Inch SAW Open Frame Touch Monitor IP65 Waterproof CCC Approved 15 Inch SAW Open Frame Touch Monitor IP65 Waterproof
Place of OriginShenzhen，China
Brand NameKeeTouch
CertificationCCC, UL, FCC, CE, CB, RoHS
Model NumberKOT-0150US-SA6BCW (KOT-150C-003)
Minimum Order Quantity1 piece
PriceNegotiable
Packaging Detailscarton box
Delivery Time7-15 work days
Payment TermsL/C, T/T, Western Union
Supply Ability1000 Pieces per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
SeriesOT,waterproofDisplay Type4:3 Ratio 15" TFT-LCD
Suggested Resolution1024*768 @ 60HzSupport Colors16.2M
Response Time (Typ.)5msContrast Ratio (Typ.)800:1
Video InputVGA/DVIProduct NameSAW Touch Monitor
High Light

CCC SAW Touch Monitor

,

Waterproof SAW Touch Monitor

,

IP65 Open Frame Touch Monitor

Leave a Message
Product Description


15 Inch SAW Touch Monitor Open Frame IP65 Waterproof



SAW Touch Monitor Main Features:

  • KeeTouch SAW touch panel, high sensitivity and good touch experience

  • High resolution SAW touch Monitor with high-quality image

  • Anti-glare, vandal-proof and IP65 front frame waterproof SAW touch monitor

  • VGA & DVI interfaces,USB for touch

  • Multiple mounting options include VESA mount, horizontal and vertical brackets mount

  • Other sizes can be offered (7"- 43")





SAW Touch Monitor Specifications

 Complete Machine

 Model No.

 KOT-0150US-SA6BCW   (P/N:KOT-150C-003)

 Series

 OT,waterproof

 Display Type

4:3 Ratio 15"   TFT-LCD

 Active Area

304.1*228.1(mm)

 Monitor Dimensions (W*H*D)

336.4*264.4*45.9(mm)

 Suggested Resolution

1024*768 @ 60Hz

 Support Colors

16.2M

 Brightness (Typ.)

Pure LCD   Panel

420cd/m2

With Touch Monitor

378cd/m2

 Response Time (Typ.)

5ms

 Viewing Angle(Typ.at CR＞10)）

 Horizontal(left/right)

 80°/80°

 Vertical(up/down)

 80°/80°

 Contrast Ratio (Typ.)

800:1

 Video Input

VGA/DVI

 Frequency (H/V)

30～60KHz / 60～75Hz

 Power Supply

Type: External brick

Display voltage: DC 12V±5%

Input (line) voltage: 100-240 VAC, 50-60   Hz

 Environment

Operating Temp.

0～50°C

Operating RH

20%～80%

Storage Temp.

-20～60°C

Storage RH

10%～90%

 MTBF

50,000   Hours

 LED Back Light Life (Typ.)

50,000   Hours

 Weight（N.W/G.W）

3.5Kg(1pcs)/11Kg(2pcs   in one package)

 Package dimensions

429*183*356(mm)(2pcs in one package)

 Power Consumption

Standby Power:   ≤1.5W / Operating Power: ≤12W

 Mount Interface

 1.VESA 75mm and 100mm

 2.Mount bracket, horizontal or vertical mount

 OSD Control

Buttons

 AUTO,+,POWER,-,MENU

Function

Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location,   Languages, Function, Reset

 Touch Screen Type

KeeTouch 15" SAW 6 mm Compact Touchscreen(anti-glare,vandal-proof)

 Touch System   Interface

Having USB and Serial(RS232) Interface

 Touch Response Time

USB/Serial: 8.4/10.4ms

 Agency approvals

 CCC, ETL, FCC,   CE, CB, RoHS

 Regular Warranty

1 year


NOTE :

① The display SPEC. are adjusted according to the selected LCD screen and touch screen

② The support system is adjusted according the specific system and version.





Applications

KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.





FAQ

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.


2. What’s your MOQ for the SAW Touch Monitor?

Our minimum order quantity is 1pc only.


3. What is your warranty period for the SAW Touch Monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).


4. Can you produce the SAW Touch Monitor according to the customer's requirements?

Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
