18.5 Inch PCAP Touch Monitor Open Frame Anti-vandal For Kiosks

18.5 Inch PCAP Touch Monitor Open Frame Anti-vandal For Kiosks
18.5 Inch PCAP Touch Monitor Open Frame Anti-vandal For Kiosks 18.5 Inch PCAP Touch Monitor Open Frame Anti-vandal For Kiosks 18.5 Inch PCAP Touch Monitor Open Frame Anti-vandal For Kiosks 18.5 Inch PCAP Touch Monitor Open Frame Anti-vandal For Kiosks 18.5 Inch PCAP Touch Monitor Open Frame Anti-vandal For Kiosks 18.5 Inch PCAP Touch Monitor Open Frame Anti-vandal For Kiosks 18.5 Inch PCAP Touch Monitor Open Frame Anti-vandal For Kiosks
Place of OriginShenZhen, China
Brand NameKeeTouch
CertificationCCC, UL, FCC, CE, CB, RoHS
Model NumberKOT-185P-007
Minimum Order Quantityone piece
PriceNegotiable
Packaging Details2pcs in one package
Delivery Time7-15 work days
Payment TermsT/T, Western Union,L/C
Supply Ability10000 Pieces per Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Screen Size18.5Regular Warranty1 Year
Suggested Resolution1366X768 @ 60HzVideo InputVGA/DVI
Display Ratio16:9Touch TechnologyCapacitive
Touch InterfaceUSBContrast Ratio1000:1
Brightness250cd/m²Input InterfaceVGA/DVI
Operating Temperature0°C-50°CPower Consumption13W
Resolution1366X768 @ 60HzResponse Time5ms
Size18.5Touch Points10
Viewing Angle85°/85°/80°/80°

High Light

pcap touch monitor high brightness

,

18.5inch pcap touch monitor

,

1000 1 contrast ratio pcap monitor

Leave a Message
Product Description

Product Description:



18.5 Inch PCAP Touch Monitor Open Frame Anti-vandal For Kiosks



This PCAP touch monitor delivers main features as below: 1366*768 high resolution, 1000:1 high contrast ratio, vandal-proof, IP65 front frame waterproof and dust-proof with wide viewing angle. Also, VGA and DVI interfaces are provided for use, USB & RS-232 ports for touch. In addition, OEM and ODM services can be offered to meet customers’individual needs.



Specification

Model No.

KOT-0185U-CA4P

Series

OT，Narrow Edge

Display Type

16:9 Ratio 18.5＂Active Matrix TFT-LCD, LED Backlight

Display Active Area

409.8(mm)×230.4(mm)



Touch Monitor Dimensions

Width: 449.4mm

Height: 270mm

Depth: 47.9mm

Suggested Resolution

1366X768 @ 60Hz

Support Colors

16.7M



Brightness(Typ.)

Pure LCD Panel

250cd/m²

With Projected Capacitive Touchscreen

212cd/m²

Response Time(Typ.)

5ms

Viewing Angle

(Typ.at CR>10)

Horizontal(Left/Right)            85°/85°

Vertical(Up/Down)                 80°/80°

Contrast Ratio(Typ.)

1000:1

Video Input

VGA/DVI

Frequency(H/V)

37.8～68.4KHz / 50～76Hz

Power Supply

Type: External Brick

Input (Line) Voltage: 100-240 VAC, 50-60 Hz



Environment

Operation Temp.

0～50°C

Storage Temp.

-20～60°C

Operation RH

20%～80%

Storage RH

10%～90%

MTBF

30,000 Hours

LED Back Light Life(Typ.)

30,000 Hours

Weight(N.W/G.W)

3.64kg(1pcs) / 8.93kg (2pcs in One Package)

Package Dimensions

525(L)*190(W)*380(H)mm   (2pcs in One Package)

Power Consumption

13W/0.6W(Stand by)

Mount Interface

1)VESA 75mm and 100mm

2)Mount Bracket, Horizontal or Vertical



OSD Control

Buttons

AUTO,+,POWER,-,MENU

Function

Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset

Touch Screen Type

18.5"Projected Capacitive 4.3mm Touchscreen (10 Points Touch for Win7)

Touch System Interface

USB / RS-232 （optional）

Touch Response Time

≦10ms

Agency Approval

CCC, UL, FCC, CE, CB, RoHS

Regular Warranty

1 Year


Applications

KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.


High Brightness 18.5inch PCAP Touch Monitor With 1000 ：1 Contrast Ratio 0



Advantages of PCAP Touch Monitor

1.High sensitivity and accuracy: PCAP touch monitors offer excellent touch sensitivity, allowing for precise touch input even with a light touch.

2.Multi-touch support: PCAP touch monitors can support multiple simultaneous touch inputs, enabling advanced gestures and providing a more intuitive user experience.

3.Durability: PCAP touch monitors are built with a robust, chemically-strengthened glass surface that is highly resistant to scratches, wear, and damage.

4.Optical clarity: The glass surface of a PCAP touch monitor provides excellent optical clarity, allowing for high-quality image reproduction.

5.Slim and lightweight design: PCAP touch monitors typically have a slim and lightweight profile, which makes them easy to integrate into various systems and installations.


FAQ

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer for over 18 years, located in Shenzhen, China.


2. What’s your MOQ for the PCAP touch monitor?

Our minimum order quantity is 1pc only.


3. What is your warranty period for the PCAP touch monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
