Pure Plat LCD PCAP Touch Monitor 27 Inch Dust Proof Anti Vandal

Pure Plat LCD PCAP Touch Monitor 27 Inch Dust Proof Anti Vandal
Pure Plat LCD PCAP Touch Monitor 27 Inch Dust Proof Anti Vandal Pure Plat LCD PCAP Touch Monitor 27 Inch Dust Proof Anti Vandal Pure Plat LCD PCAP Touch Monitor 27 Inch Dust Proof Anti Vandal Pure Plat LCD PCAP Touch Monitor 27 Inch Dust Proof Anti Vandal Pure Plat LCD PCAP Touch Monitor 27 Inch Dust Proof Anti Vandal
Place of OriginShenzhen, China
Brand NameKeeTouch
CertificationFCC, CE, CB, RoHS, UL, BIS
Model NumberKOT-270P-006(KOT-0270U-CA2P)
Minimum Order Quantity1 piece
PriceNegotiable
Packaging DetailsCarton
Delivery Time7-15 work days
Payment TermsT/T, L/C, Western Union
Supply Ability10000 Pieces per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Response Time (Typ.)12msDisplay Type16:9 Ratio 27" TFT-LCD,LED Backlight
Support Colors16.7MVideo InputVGA/DVI/HDMI
Frequency (H/V)30～80KHz / 50～75HzLED Back Light Life (Typ.)≥30,000 Hours
Support SystemXP, WIN7, WIN8, WIN10, Linux, AndroidLight Transmittance≥85%
Product NamePCAP Touch MonitorWarrantyOne Year
High Light

Anti Vandal PCAP Touch Monitor

,

PCAP Touch Monitor Dust Proof

,

PCAP 27 Inch Touch Monitor

Leave a Message
Product Description


27 Inch PCAP Touch Monitor Pure Plat Design 3000:1 Contrast Ratio


PCAP Touch Monitor Main Features

  • PCAP multi-touch screen, accurate touch and fast response
  • Dust-proof and anti-vandal PCAP touch monitor with full viewing angle
  • 3000:1 high contrast ratio, high clarity image with high definition visual enjoyment
  • Pure flat designed PCAP touch monitor with IP65 front side waterproof
  • Support system: Windows7
  • VGA/DVI/DHMI interfaces, USB for touch input
  • Multiple mounting options include VESA mount, horizontal vertical brackets mount
  • Other sizes are available (7’’-43’’)





PCAP Touch Monitor Specifications



Complete Machine
Model No.KOT-0270U-CA2P (P/N:KOT-270P-006)
SeriesOT
Display Type16:9 Ratio 27" TFT-LCD,LED backlight
Active Area599.3*337.8(mm)
Monitor Dimensions (W*H*D)655.9*394.4*48.5(mm)
Suggested Resolution1920*1080 @ 60Hz
Brightness (Typ.)Pure LCD Panel300cd/㎡
With Touch Monitor250cd/㎡
Response Time (Typ.)12ms
Viewing Angle(Typ.at CR＞10))Horizontal(left/right)89°/89°
 Vertical(up/down)89°/89°
Contrast Ratio (Typ.)3000:1
Video InputVGA/DVI/HDMI
Frequency (H/V)30～80KHz / 50～75Hz
Power SupplyType: External brick
Display voltage: DC 12V±5%
Input (line) voltage: 100-240 VAC, 50-60 Hz
EnvironmentOperating Temp.0～50°C
Operating RH20%～80%
Storage Temp.-20～60°C
Storage RH10%～90%
MTBF≥30,000 Hours
LED Back Light Life (Typ.)≥30,000 Hours
Power ConsumptionStandby Power: ≤2W / Operating Power: ≤35W
Mount Interface1.VESA 75mm and 100mm
2.Mount bracket, horizontal or vertical mount
OSD ControlButtonsAUTO,+,POWER,-,MENU
FunctionBrightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Touch Type27" Capacitive screen
Touch inputUSB
Support SystemXP,WIN7,WIN8,WIN10,Linux,Android
Agency approvalsCCC, UL, FCC, CE, CB, RoHS
Regular Warranty1 year













NOTE :

① The display SPEC. are adjusted according to the selected LCD screen and touch screen

② The support system is adjusted according the specific system and version.






PCAP Touch Monitor Mechanical Dimensions



Pure Plat LCD PCAP Touch Monitor 27 Inch Dust Proof Anti Vandal 0






Applications

KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.








FAQ

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer founded in 2006, located in Shenzhen, China.



2. What’s your MOQ for the PCAP Touch Monitor?

Our minimum order quantity is 1pc only.



3. What is your warranty period for the PCAP Touch Monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).



4. Can you produce the PCAP Touch Monitor according to the customer's requirements?

Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.



5. What is your payment method?

We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )



6. What is your delivery time?

3-5 work days for inventory orders, 7-15 business days for bulk production.
