PCAP 32 Inch Touch Screen Display , Panel Touch Screen Monitor For Gaming
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Suggested Resolution | 1920x1080 @ 60Hz | Contrast Ratio (Typ.) | 2100:1 （Min.） /3000:1(Typ.) |
|---|---|---|---|
| Video Input | VGA\DVI | Support Colors | 16.7M |
| Response Time | 21s | Thickness | 3.8±0.2(mm) |
| Touch Test | ≥50,000,000 Times | Product Name | PCAP Touch Monitor |
| High Light | PCAP 32 Inch Touch Screen Display,Gaming 32 Inch Touch Screen Display,32Inch Panel Touch Screen Monitor | ||
Product Description
32 Inch Touch Screen Monitors LED Light Pot O Gold Gaming Touch Panel Monitors
PCAP Touch Monitor Description
This Curved PCAP touch monitor is designed with LED strips and uses industrial LCD panel with FHD 1920x1080, ultrafast refresh rate, wide viewing angel, rich colors, which can deliver an immersive experience. They can be connected by VGA, HDMI, DVI interfaces, USB for touch and also support XP, WIN7, WIN8, WIN10, Linux, Android operating systems.
PCAP Touch Monitor Specifications
Complete Machine | ||
Model No. | KOT-320P-026 | |
Series | OT | |
Display Type | 16:9 Ratio 32" TFT-LCD | |
Active Area | 698.4 x 392.85(mm) | |
Monitor Dimensions (W*H*D) | 768.4*456*109.6(mm) | |
Suggested Resolution | 1920x1080 @ 60Hz | |
Support Colors | 16.7M | |
Brightness (Typ.) | Pure LCD Panel | 250cd/m² |
With Touch Monitor | 213cd/m² | |
Viewing Angle(Typ.at CR＞10)） | 89°/89°(Typ.)/80°/80°(Min.) | |
89°/89°(Typ.)/80°/80°(Min.) | ||
Contrast Ratio (Typ.) | 2100:1 （Min.） /3000:1(Typ.) | |
Video Input | VGA/DVI | |
Frequency (H/V) | 54.15～84.38KHz / 49～72Hz | |
Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz | |
Environment | Operating Temp. | 0～50°C |
Operating RH | 20%～80% | |
Storage Temp. | -20～60°C | |
Storage RH | 10%～90% | |
MTBF | ≥30,000 Hours | |
LED Back Light Life (Typ.) | ≥30,000 Hours | |
Power Consumption | Standby Power: ≤2W / Operating Power: ≤40W | |
Mount Interface | VESA 200mm | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
Regular Warranty | 1 year | |
Touch Screen | |
Touch Type | 32" Capacitive touch screens |
Touch input | USB |
Response Time | ≤14ms |
Hardness | 6H |
Light Transmittance | ≥85% |
Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
Active Area | 692.7*392(mm) |
Thickness | 3.8±0.2(mm) |
Touch Test | ≥50,000,000 times |
Input Voltage | DC 5V±5% |
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer founded in 2006, located in Shenzhen, China.
2. What’s your MOQ for the PCAP Touch Monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the PCAP Touch Monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Can you produce the PCAP Touch Monitor according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Credit card, and Alipay.(L/C can be negotiable.)
