21.5 Inch PCAP Touch Monitor 1000:1 Contrast Ratio VGA/DVI For Self-Service Kiosks
| Place of Origin | Shenzhen, China |
|---|---|
| Brand Name | KeeTouch |
| Certification | CCC, UL, FCC, CE, CB, RoHS |
| Model Number | KOT-0215U-CA4P (KOT-215P-014) |
| Minimum Order Quantity | 1 piece |
| Price | Negotiable |
| Packaging Details | 1pcs in one package |
| Delivery Time | 7-15 work days |
| Payment Terms | T/T, Western Union,L/C |
| Supply Ability | 10000 Pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Touch Type | 21.5" Capacitive Touch Screens | LED Back Light Life | 30,000 Hours |
|---|---|---|---|
| Contrast Ratio | 1000:1 | Response Time | 5ms |
| Screen Size | 21.5 Inch | Regular Warranty | 1 Year |
| Operating Temp | 0～50°C | Suggested Resolution | 1920x1080 @ 60Hz |
Product Description
21.5 Inch PCAP Touch Monitor 1000:1 Contrast Ratio VGADVI For Self-Service Kiosks
The PCAP Touch Monitor is a multi-touch interactive display for a variety of applications. This 21.5" capacitive touch screen offers a beautiful LED back light display with 1000:1 contrast ratio and 1920x1080 resolution. The LED back light life is 30,000 hours, and the touch test is ≥50,000,000 times, making it a dependable and durable option. The capacitive touch screen of the PCAP Touch Monitor allows for precise, smooth, and accurate multi-touch operations, perfect for gaming, office work, digital signage, and more.
Specification:
Complete Machine | ||
Model No. | KOT-0215U-CA4P (P/N:KOT-215P-014) | |
Series | ||
Display Type | 16:9 Ratio 21.5" TFT-LCD | |
Active Area | 476.6*269 (mm) | |
Monitor Dimensions (W*H*D) | 512.1*307.3*47(mm) | |
Suggested Resolution | 1920*1080 @ 60Hz | |
Support Colors | 16.7M | |
Brightness (Typ.) | Pure LCD Panel | 250cd/㎡ |
With Touch Monitor and Peep-proof protection film | 127cd/㎡ | |
Response Time (Typ.) | 5ms | |
Viewing Angle(Typ.at CR＞10)） | Horizontal(left/right) | 85°/85° |
Vertical(up/down) | 80°/80° | |
Contrast Ratio (Typ.) | 1000:1 | |
Video Input | VGADVI | |
Frequency (H/V) | 37.9～80KHz / 60～75Hz | |
Power Supply | Type: External brick Display voltage: DC 12V±5% | |
Environment | Operating Temp. | 0～50°C |
Operating RH | 20%～80% | |
Storage Temp. | -20～60°C | |
Storage RH | 10%～90% | |
MTBF | ≥30,000 Hours | |
LED Back Light Life (Typ.) | ≥30,000 Hours | |
Weight（N.W/G.W） | 5.6Kg(1pcs)/13.4Kg(2pcs in one package) | |
Package dimensions | 605*400*195(mm)(2pcs in one package) | |
Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤30W | |
Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
CCC, UL, FCC, CE, CB, RoHS | ||
Regular Warranty | 1 year | |
Touch Screen | |
Touch Type | 21.5" Capacitive touch screens |
Touch input | USB |
Response Time | ≤10ms |
Hardness | 6H |
Light Transmittance | ≥85% |
Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
Active Area | 479.04*270.51(mm) |
Thickness | 4.3±0.3(mm) |
Touch Test | ≥50,000,000 times |
Input Voltage | DC 5V±5% |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
Applications:
This touch monitors are widely used in industries such as retail, gaming, public service, self-service, finance, transit, conference, kiosk, education, healthcare, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Support and Services:
PCAP Touch Monitor Technical Support and Services
- Comprehensive technical support and troubleshooting assistance
- Upgrades and updates for the latest products and features
- Onsite installation and setup
- Warranty and repair services
- Custom programming and development
- Remote monitoring and support
Packing and Shipping:
PCAP Touch Monitor packaging and shipping requires special care to ensure the safety of the product. Here are some guidelines to follow when packing and shipping PCAP Touch Monitors:
- Use a box that is large enough to fit the monitor with at least 2 inches of packing material surrounding it.
- Securely tape all openings, flaps and seams of the box.
- Place the monitor in the center of the box with the screen facing up.
- Fill in all empty space with packing material such as bubble wrap or packing peanuts.
- Label the box with the appropriate shipping information.
Drop off the package at your local shipping facility.
FAQ:
Q: Where is the PCAP Touch Monitor produced?
A: Our PCAP Touch Monitor is produced in Shenzhen, China.
Q: What certifications does the PCAP Touch Monitor have?
A: Our PCAP Touch Monitor has CCC, UL, FCC, CE, CB, and RoHS certifications.
Q: What is the minimum order quantity for PCAP Touch Monitor?
A: The minimum order quantity for our PCAP Touch Monitor is one piece.
