High Sensitivity PCAP Touch Display Fast Response Dust Resistant
| Place of Origin | ShenZhen, China |
|---|---|
| Brand Name | KeeTouch |
| Certification | CCC, UL, FCC, CE, CB, RoHS |
| Model Number | KOT-097P-003（KOT-0907U-CA4P） |
| Minimum Order Quantity | one piece |
| Price | Negotiable |
| Packaging Details | 1pc in one package |
| Delivery Time | 7-15 working days |
| Payment Terms | T/T, Western Union,L/C |
| Supply Ability | 10000 Pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Screen Size | 9.7 inch | Regular Warranty | 1 Year |
|---|---|---|---|
| Suggested Resolution | 1024*768 | Display Ratio | 4:3 |
| Touch Technology | Projected Capacitive | Touch Interface | USB |
| Contrast Ratio | 500:1 | Brightness | 300cd/m² |
| Input Interface | VGA/DVI | Power Consumption | 12W |
| Response Time | 20ms | Touch Points | 10 |
| Viewing Angle | 70°/70°/80°/80° | LED Back Light Life | 10,000 Hours |
| Touch Screen Resolution | 16384*9600 | ||
| High Light | High Sensitivity PCAP Touch Display,Fast Response PCAP Touch Display,Dust Resistant PCAP Touchscreen | ||
Product Description
9.7 Inch PCAP Touch Monitor Multi-touch 1024*768 Resolution For Kiosk
This 9.7 inch PCAP touch monitor comes with projected capacitive touch technology with good clarity and image quality. It supports multi-touch, with high sensitivity and fast response, providing users with an excellent interactive experience. It includes a VGA and a DVI video interfaces, as well as a USB port for touch.
Specification:
Complete Machine | ||||
Model No. | KOT-097P-003 | |||
Type | OT | |||
Display Type | 4:3 Ratio 9.7＂TFT-LCD, LED backlight | |||
Active Area | 196.6 x 147.46mm | |||
Monitor Dimensions (W*H*D) | 259*215*38.8(mm) | |||
Suggested Resolution | 1024*768 | |||
Support Colors | 16.7M | |||
Brightness (Typ.) | Pure LCD Panel | 300cd/m²(Typ.)/220cd/m²(Min.) | ||
With Touch Monitor | 238cd/m²(Typ.)/167cd/m²(Min.) | |||
Response Time (Typ.) | 20ms | |||
Viewing Angle(Typ.at CR＞10)） | Horizontal(left/right) | 70 °/70 °(Typ.)/ 60 °/70 °(Min.) | ||
Vertical(up/down) | 80 °/80 °(Typ.)/70 °/80 °(Min.) | |||
Contrast Ratio (Typ.) | 500:1(Typ.)/400:1(Min.) | |||
Video Input | VGA/DVI | |||
Frequency (H/V) | 43.86～60KHz / 60～75Hz | |||
Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz The DC inner diameter of power adapter: 2.1mm | |||
Environment | Operating Temp. | 0～50°C | ||
Operating RH | 20%～80% | |||
Storage Temp. | -20～60°C | |||
Storage RH | 10%～90% | |||
MTBF | ≥ 10,000 hours | |||
LED Back Light Life (Typ.) | ≥ 10,000 hours | |||
Weight(N.W/G.W) | 2Kg(1pc)/4.5Kg(2pcs in one package) | |||
Package dimensions | 259.38*215.48*39.66(mm)(2pcs in one package) | |||
Power Consumption | Standby Power: ≤1.5W Operating Power: ≤12W | |||
Mount Interface | 1. VESA 75mm 2.Mount bracket, horizontal or vertical mount | |||
OSD Control | Buttons | Confirm, MENU, AUTO, Up, Down, Power | ||
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |||
Regular Warranty | 1 year | |||
Touch Screen | |
Touch Type | 9.7inch Projected Capacitive Riot-proof Touch Screen |
Touch input | USB |
Response Time | ≤15ms |
Touch Screen Resolution | 16384*9600 |
Hardness | 6H |
Light Transmittance | >85% |
Riot Test | Meets 130g Steel Ball, 50cm Drop Experiment |
Support System | WIN7、WIN8、WIN10 support 10 points, XP support single point |
Active Area | 197.6*148.5(mm) |
Thickness | 1.85±0.2(mm) |
Touch Test | ≥ 50,000,000 times |
Input Voltage | DC 5V±5% |
Mechanical Dimensions:
Applications:
PCAP Touch Monitor are widely used in retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Why choose us?
1. Quality products: All our products have passed strict quality inspection by the quality department before shipment.
2. Competitive pricing: With a strong supply chain, the prices of our products are very competitive.
3. Timely delivery: We have raw materials in stock all year round, the goods can be produced and sent out quickly.
4. Responsive Customer Service: Professional after-sales team at any time to provide services to customers.
FAQ:
1. Are you a manufacturer?
Yes, KeeTouch, based in Shenzhen, China, boasts over 17 years of experience as a premier manufacturer of touch products.
2. What is your payment method?
We can accept T/T, Western Union, Paypal, Credit card, and Alipay.(L/C can be negotiable.)
3. Do you give any discount for the PCAP touch monitor?
We will do utmost to support you with the competitive price, also good service will be offered.
