10ms Capacitive Multi Touch Monitor 19 Inch Ip65 WaterProof
| Place of Origin | Shenzhen，China |
|---|---|
| Brand Name | KeeTouch |
| Certification | CCC, UL, FCC, CE, CB, RoHS |
| Model Number | KOT-0190U-CA2P169(PN KOT-190P-038) |
| Minimum Order Quantity | 1 piece |
| Price | Negotiable |
Packaging Details | 2pcs in one package |
| Delivery Time | 7-15 work days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 10000 Pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Display Type | 16:10 Ratio | Contrast Ratio | 1000:1 |
|---|---|---|---|
| Video Input | VGA/DVI | Frequency(H/V) | 30～80KHz / 60～75Hz |
| Touch Response | ≦10ms | Operating Temp | 0～50°C |
| Touch Input | USB | Regular Warranty | 1 Year |
| High Light | 19 inch capacitive multi touch monitor,ip65 capacitive multi touch monitor,water proof capacitive touch monitor | ||
Product Description
19 Inch PCAP Touch Monitor IP65 Waterproof for Kiosks
This PCAP touch monitor comes with anti-vandal functions and IP65 front frame water-proof, delivering superior quality image with great touch experience. The VGA, DVI and USB interfaces are provided for use. With our own R&D department, customized services can be offered. Besides, other sizes (7’’-43’’) are for your option.
Specification of PCAP Touch Monitor
Model No. | KOT-0190U-CA2P169 (PN: KOT-190P-038) | |||
Series | OT, Wide-screen , LED backlight | |||
Display Type | 16:10 Ratio 19" Active matrix TFT-LCD | |||
Display Active Area | 408.5×255. 5(mm) | |||
Touch Monitor Dimensions | Width: 452mm | |||
Suggested Resolution | 1440×900 @ 60Hz | |||
Support Colors | 16.7M | |||
Brightness(Typ.) | Pure LCD Panel (Brightness from 300~1000nits can be customized ) | 250cd/m² | ||
With Projected Capacitive Touchscreen | 212cd/m² | |||
Response Time(Typ.) | 5ms | |||
Viewing Angle (Typ.at CR>10) | Horizontal(left/right): 85°/85° | |||
Vertical(up/down): 80°/80° | ||||
Contrast Ratio(Typ.) | 1000:1 | |||
Video Input | VGA and DVI | |||
Frequency(H/V) | 30～80KHz / 60～75Hz | |||
Power Supply | Type: External brick | |||
Environment | Operation Temp. | 0～50°C | ||
Storage Temp. | -20～60°C | |||
Operation RH | 20%～80% | |||
Storage RH | 10%～90% | |||
MTBF | 30,000 Hours | |||
LED Back Light Life(Typ.) | 30,000 Hours | |||
Weight(N.W/G.W) | 5.5Kg(1pcs) / 13.75Kg (2pcs in one package) | |||
Package Dimension | 525×220×380(mm)(2pcs in one package) | |||
Mount Interface | 1)VESA 75mm and 100mm 2)Mount bracket, horizontal or vertical | |||
OSD Control | Buttons | AUTO,+,POWER,-,MENU | ||
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |||
Touch Screen Type | 19" Projected Capacitive touch sceen, 10 points in win7 | |||
Touch System Interface | USB / RS-232（optional） | |||
Touch Response time | 10ms | |||
Agency Approval | CCC, UL, FCC, CE, CB, RoHS | |||
Regular Warranty | 1 Year | |||
Application:
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Advantages of PCAP Touch Monitor
1. High sensitivity and accuracy: PCAP touch monitors offer excellent touch sensitivity, allowing for precise touch input even with a light touch.
2. Multitouch support: PCAP touch monitors can support multiple simultaneous touch inputs, enabling advanced gestures and providing a more intuitive user experience.
3. Durability: PCAP touch monitors are built with a robust, chemically-strengthened glass surface that is highly resistant to scratches, wear, and damage.
4. Optical clarity: The glass surface of a PCAP touch monitor provides excellent optical clarity, allowing for high-quality image reproduction.
5. Slim and lightweight design: PCAP touch monitors typically have a slim and lightweight profile, which makes them easy to integrate into various systems and installations.
FAQ:
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product
manufacturer founded in 2006, located in Shenzhen, China.
2. What’s your MOQ for the PCAP Touch Monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the PCAP Touch Monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. What is your payment method?
We can accept T/T, Western Union, Paypal,
Credit card, and Alipay.(L/C can be negotiable.)
5. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk production.
