Pcap Multi Touch Screen Monitor 1920x1080 Resolution Ip65 Waterproof 21.5 Inch
| Place of Origin | ShenZhen, China |
|---|---|
| Brand Name | KeeTouch |
| Certification | CCC, UL, FCC, CE, CB, RoHS |
| Model Number | KOT-215P-011(KOT-0215U-CA4P) |
| Minimum Order Quantity | one piece |
| Price | Negotiable |
Packaging Details | 1pcs in one package |
| Delivery Time | 7-15 work days |
| Payment Terms | T/T, Western Union,L/C |
| Supply Ability | 10000 Pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Screen Size | 21.5 Inch | Contrast Ratio | 1000:1 |
|---|---|---|---|
| Mount Interface | Vest Mount, Horizontal Or Vertical Mount | Touch Technology | Projected Capacitive Touch |
| Regular Warranty | 1 Year | Operating Temp | 0～50°C |
| Display Ratio | 16:9 | Resolution | 1920x1080 |
| High Light | vandal proof multi touch screen monitor,pcap multi touch screen monitor,ip65 pcap monitor | ||
Product Description
This 21.5 inch PCAP touch monitor comes with Projected Capacitive touch technology with high resolution and high-quality image. It supports multi-point touch, great interactive experience, which also comes with dust proof, vandal proof and IP65 waterproof functions. Besides, other sizes are available (7''- 43'').
Technical Parameters:
Complete Machine | ||
Model No. | KOT-0215U-CA4P (P/N:KOT-215P-011) | |
Series | OT | |
Display Type | 16:9 Ratio 21.5" TFT-LCD | |
Active Area | 478*270(mm) | |
Monitor Dimensions (W*H*D) | 516*311*40(mm) | |
Suggested Resolution | 1920x1080 @ 60Hz | |
Support Colors | 16.7M | |
Brightness (Typ.) | Pure LCD Panel | 250cd/m² |
With Touch Monitor | 212cd/m² | |
Response Time (Typ.) | 5ms | |
Viewing Angle(Typ.at CR＞10)） | 85°/85° | |
80°/80° | ||
Contrast Ratio (Typ.) | 1000:1 | |
Video Input | VGA/DVI/HDMI | |
Frequency (H/V) | 30～80KHz / 60～75Hz | |
Power Supply | Type: External brick Display voltage: DC 12V±5% | |
Environment | Operating Temp. | 0～50°C |
Operating RH | 20%～80% | |
Storage Temp. | -20～60°C | |
Storage RH | 10%～90% | |
MTBF | ≥30,000 Hours | |
LED Back Light Life (Typ.) | ≥30,000 Hours | |
Package dimensions | 610*410*145(mm)(1pcs in one package) | |
Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤30W | |
Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
CCC, UL, FCC, CE, CB, RoHS | ||
Regular Warranty | 1 year | |
Touch Screen | |
Touch Type | 21.5" Capacitive touch screens |
Touch input | USB |
Response Time | ≤10ms |
Hardness | 6H |
Light Transmittance | ≥85% |
Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
Active Area | 477.6*269(mm) |
Touch Test | ≥50,000,000 times |
Input Voltage | DC 5V±5% |
Applications:
PCAP Touch Monitor are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Customization:
KeeTouch KOT-0215U-CA4P PCAP Touch Screen Monitor
- Brand Name: KeeTouch
- Model Number: KOT-0215U-CA4P
- Place of Origin: ShenZhen, China
- Certification: CCC, UL, FCC, CE, CB, RoHS
- Minimum Order Quantity: one piece
- Price: Negotiable
- Packaging Details: 1pcs in one package
- Delivery Time: 7-15 work days
- Payment Terms: T/T, Western Union,L/C
- Supply Ability: 10000 Pieces per Week
- Operating System: XP, WIN7, WIN8, WIN10, Linux, Android
- Video Input: VGA/DVI/HDMI
- Touch Interface: USB
- Regular Warranty: 1 Year
- Mount Interface: Vest Mount, Horizontal Or Vertical Mount
The KeeTouch KOT-0215U-CA4P PCAP Touch Screen Monitor offers outstanding performance with its premium certified UL, CE, CB, RoHS, XP, WIN7, WIN8, WIN10, Linux, Android, USB, Vest Mount, Horizontal Or Vertical Mount. It is designed to provide the ultimate user experience with its fast and accurate touch response. The monitor's high-resolution display and wide viewing angle make it perfect for any application. And its Vest Mount, Horizontal Or Vertical Mount allows for easy installation and maintenance. The KeeTouch KOT-0215U-CA4P PCAP Touch Screen Monitor is your perfect solution for all your PCAP needs.
FAQ:
1. Can you produce the PCAP touch monitor according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
2. What is your payment method?
We can accept T/T, Western Union, Paypal, Credit card, and Alipay.(L/C can be negotiable.)
3. What is your delivery time for the PCAP touch monitor?
3-5 work days for inventory orders, 7-15 business days for bulk production.
