Usb 23 Inch Pcap Touch Monitor Ip65 Waterproof Vandal Proof
| Place of Origin | Shenzhen，China |
|---|---|
| Brand Name | KeeTouch |
| Certification | CCC, FCC, UL, CE, CB, RoHs |
| Model Number | KOT-0230U-CA5P (KOT-230P-003) |
| Minimum Order Quantity | 1 piece |
| Price | Negotiable |
Packaging Details | 2pcs in one package |
| Delivery Time | 7-15 work days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 10000 Pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Display Type | 16:9 Ratio | Resolution | 1920×1080 @ 60Hz |
|---|---|---|---|
| Contrast Ratio | 1000:1 | Video Input | VGA And DVI And HDMI |
| Frequency(H/V) | 30～80KHz / 60～75Hz | Touch Response | ≤10ms |
| Operating Temp | 0～50°C | ||
| High Light | vandalproof pcap touch monitor,ip65 pcap touch monitor,23 inch pcap monitor | ||
Product Description
23 Inch PCAP Touch Monitor IP65 Waterproof Vandal-Proof With Touch Lcd Screen
This 23 inch PCAP touch monitor comes with Projected Capacitive touch technology with high resolution, high-quality image and full viewing angle. This touch monitor supports multi-point touch, with great interactive experience, which also comes with LED flexible stripes, ideal choice for gaming. Besides, it also supports multiple mounting options, including VESA mount, horizontal and vertical brackets mount.
Specification of PCAP Touch Monitor
Complete Machine | ||
Model No. | KOT-0230U-CA5P | |
Series | OT , With LED Flexible Stripes | |
Display Type | 16:9 Ratio 23” Active matrix TFT-LCD | |
Active Area | 511.8mm×289mm | |
Monitor Dimensions (W*H*D) | 588.2*365.4*45(mm) | |
Suggested Resolution | 1920x1080 @ 60Hz | |
Support Colors | 16.7M | |
Brightness (Typ.) | Pure LCD Panel (Brightness from 300~1000cd/m² can be customized) | 250 cd/m² |
With Projected Capacitive Touchscreen | 212 cd/m² | |
Response Time (Typ.) | 14ms | |
Viewing Angle(Typ.at CR＞10)） | ||
Contrast Ratio (Typ.) | 1000:1 | |
Video Input | VGA/HDMI/DVI | |
Frequency (H/V) | 30～80KHz / 60～75Hz | |
Power Supply | Type: External brick Input (line) voltage: 100-240 VAC, 50-60 Hz | |
Environment | Operating Temp. | 0～50°C |
Operating RH | 20%～80% | |
Storage Temp. | -20～60°C | |
Storage RH | 10%～90% | |
MTBF | ≥30,000 Hours | |
LED Back Light Life (Typ.) | ≥30,000 Hours | |
Weight（N.W/G.W） | 7.5kg/17.3kg(2 pcs) | |
Package dimensions | 703×181×485(mm) (2pcs in one package) | |
Power Consumption | 37W(approximately, Includes touch display and LED lamp) | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
CCC, UL, FCC, CE, CB, RoHS | ||
Regular Warranty | 1 year | |
Touch Screen | |
Touch Type | 23” Projected Capacitive Touchscreen 10 Points Touch |
Touch Input | USB |
Response Time | ≤10ms |
Hardness | 7H |
Light Transmittance | ≥85% |
Active Area | 511.8mm×289mm |
Thickness | 4.3±0.2(mm) |
Touch Test | More than 50,000,000 touches in one location without failure |
Input Voltage | DC 5V±5% |
Application:
PCAP Touch Monitor are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Why choose us?
1. We are a leading provider of industrial grade touch products and touch solutions, Keetouch founded in 2006.
2. Our core competence is differentiated product customization. With over 40 professional R&D engineers, we can offer OEM and ODM services to meet customer's individual requirements.
3. Our company has been approved by ISO9001 and ISO14001, and with the certifications CCC, UL, FCC, CE, CB, BIS, RoHS, etc. for the products.
4. Professional after-sales team at any time to provide services to customers.
FAQ:
1. Can you produce the PCAP touch monitor according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
2. What is your payment method?
We can accept T/T, Western Union, Paypal, Credit card, and Alipay.(L/C can be negotiable.)
3. What is your delivery time for the PCAP touch monitor?
3-5 work days for inventory orders, 7-15 business days for bulk production.
