23 Inch Projected Capacitive Touch Screen Monitor With 1920x1080 Resolution
| Place of Origin | Shenzhen，China |
|---|---|
| Brand Name | KeeTouch |
| Certification | CCC, FCC, UL, CE, CB, RoHs |
| Model Number | KOT-0230U-CA5P (KOT-230P-003) |
| Minimum Order Quantity | 1 piece |
| Price | Negotiable |
Packaging Details | 2pcs in one package |
| Delivery Time | 7-15 work days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 10000 Pieces per Week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Display Type | 16:9 Ratio | Resolution | 1920×1080 @ 60Hz |
|---|---|---|---|
| Contrast Ratio | 1000:1 | Video Input | VGA And DVI And HDMI |
| Frequency(H/V) | 30～80KHz / 60～75Hz | Touch Response | ≤10ms |
| Operating Temp | 0～50°C | Support Colors | 16.7M |
| Display Response | 14ms | ||
| High Light | 23inch projected capacitive touch screen monitor,1920x1080 projected capacitive touch screen monitor,high resolution pcap monitor | ||
Product Description
23 Inch PCAP Touch Monitor Open Frame Touchscreen With 1920x1080 Resolution
This 23 inch PCAP touch monitor is industrial grade touch monitor, which can be used normally in harsh environments. Also, it has dust-proof, vandal-proof and IP65 waterproof functions. VGA, DVI and HDMI interfaces are provided for use, USB port for touch. With our professional R&D engineers, customized services can be offered to meet customers’ individual requirements. Besides, it can support various operation systems: XP,WIN7,WIN8,WIN10, Linux, Android.
Specification of PCAP Touch Monitor
Complete Machine | ||
Model No. | KOT-0230U-CA5P | |
Series | OT , With LED Flexible Stripes | |
Display Type | 16:9 Ratio 23” Active matrix TFT-LCD | |
Active Area | 511.8mm×289mm | |
Monitor Dimensions (W*H*D) | 588.2*365.4*45(mm) | |
Suggested Resolution | 1920x1080 @ 60Hz | |
Support Colors | 16.7M | |
Brightness (Typ.) | Pure LCD Panel (Brightness from 300~1000cd/m² can be customized) | 250 cd/m² |
With Projected Capacitive Touchscreen | 212 cd/m² | |
Response Time (Typ.) | 14ms | |
Viewing Angle(Typ.at CR＞10)） | ||
Contrast Ratio (Typ.) | 1000:1 | |
Video Input | VGA/HDMI/DVI | |
Frequency (H/V) | 30～80KHz / 60～75Hz | |
Power Supply | Type: External brick Input (line) voltage: 100-240 VAC, 50-60 Hz | |
Environment | Operating Temp. | 0～50°C |
Operating RH | 20%～80% | |
Storage Temp. | -20～60°C | |
Storage RH | 10%～90% | |
MTBF | ≥30,000 Hours | |
LED Back Light Life (Typ.) | ≥30,000 Hours | |
Weight（N.W/G.W） | 7.5kg/17.3kg(2 pcs) | |
Package dimensions | 703×181×485(mm) (2pcs in one package) | |
Power Consumption | 37W(approximately, Includes touch display and LED lamp) | |
Mount Interface | VESA 100*300mm and 100*400mm | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
CCC, UL, FCC, CE, CB, RoHS | ||
Regular Warranty | 1 year | |
Touch Screen | |
Touch Type | 23” Projected Capacitive Touchscreen 10 Points Touch |
Touch Input | USB |
Response Time | ≤10ms |
Light Transmittance | ≥85% |
Active Area | 511.8mm×289mm |
Thickness | 4.3±0.2(mm) |
Touch Test | More than 50,000,000 touches in one location without failure |
Input Voltage | DC 5V±5% |
Application:
PCAP Touch Monitor are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Why choose us?
1. Quality products: All our products have passed strict quality inspection by the quality department before shipment.
2. Competitive pricing: With a strong supply chain, our products’ prices are very competitive.
3. Timely delivery: We have raw materials in stock all year round, the goods can be produced and sent out quickly.
4. Responsive Customer Service: Professional after-sales team at any time to provide services to customers.
FAQ:
1. What package do you provide for the PCAP touch monitor?
Our package usually is carton.
2. Do you have stock?
Yes, we have a large quantity of stock for our regular model products.
3. What are the shipping ways?
We will ship the goods according to customer’s requirement. For sample, normally by FedEx, DHL, UPS, TNT. For bulk order, by air or by sea.
4. Do you give any discount for the PCAP touch monitor?
We will do utmost to support you with the competitive price, also good service will be offered.
