23.8 Inch Pcap Touch Monitor 1920x1080 High Resolution For Kiosks

23.8 Inch Pcap Touch Monitor 1920x1080 High Resolution For Kiosks
23.8 Inch Pcap Touch Monitor 1920x1080 High Resolution For Kiosks 23.8 Inch Pcap Touch Monitor 1920x1080 High Resolution For Kiosks 23.8 Inch Pcap Touch Monitor 1920x1080 High Resolution For Kiosks 23.8 Inch Pcap Touch Monitor 1920x1080 High Resolution For Kiosks 23.8 Inch Pcap Touch Monitor 1920x1080 High Resolution For Kiosks
Place of OriginShenZhen, China
Brand NameKeeTouch
CertificationCCC, UL, FCC, CE, CB, RoHS
Model NumberKOT-238P-005

Minimum

Order Quantity

one piece
PriceNegotiable

Packaging

Details

1pc in one package
Delivery Time7-15 work days
Payment TermsT/T, Western Union,L/C
Supply Ability10000 Pieces per Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Contrast Ratio3000:1Touch TechnologyProjected Capacitive Touch
Operating Temp0～50°CResolution1920x1080
Display Ratio16:9Touch InterfaceUSB
Video InputVGA/DVI/HDMIMount InterfaceVest Mount, Horizontal Or Vertical Bracket Mount
High Light

23.8 inch pcap touch monitor

,

1920x1080 pcap touch monitor

,

pcap monitor for kiosks

Leave a Message
Product Description


Description of PCAP Touch Monitor


23.8 Inch PCAP Touch Monitor Touch LCD Screen 1920x1080 High Resolution For Kiosks


This PCAP touch monitor delivers main features as below: 1920*1080 high resolution, 3000:1 high contrast ratio, vandal-proof, IP65 front frame waterproof and dust-proof with wide viewing angle. The PCAP touch monitor is industrial grade, durable and high-quality, which can be normally used in harsh environment. Besides, OEM and ODM services can be offered to meet customers’ individual needs.





Features:

Product Name: PCAP Touch Monitor

PCAP Touch Screen Panel

Multi-Touch Digital Monitor

PCAP Touch Screen Monitor

Display Ratio: 16:9

Touch Technology: Projected Capacitive Touch

Contrast Ratio: 3000:1

Video Input: VGA/DVI/HDMI

Regular Warranty: 1 Year





Specification of PCAP Touch Monitor:


 Complete Machine

 Model No.

 KOT-0240U-CA2P (P/N:KOT-238P-005)

 Series

 OT

 Display Type

16:9 Ratio 23.8" TFT-LCD

 Active Area

527.04(H) x 296.46(V)(mm)

 Monitor Dimensions (W*H*D)

580.5*350*48.7(mm)

 Suggested Resolution

1920*1080 @ 60Hz

 Support Colors

16.7M

 Brightness (Typ.)

Pure LCD Panel

250cd/m²

With Touch Monitor

212cd/m²

 Response Time (Typ.)

12ms

 Viewing Angle(Typ.at CR＞10)）

 Horizontal(left/right)

 89°/89°(Typ)/ 75°/75°(Min.)

 Vertical(up/down)

 89°/89°(Typ)/ 75°/75°(Min.)

 Contrast Ratio (Typ.)

3000:1(Typ.)/1800:1(Min.)

 Video Input

VGA/DVI/HDMI

 Frequency (H/V)

37.9～80KHz / 60～75Hz

 Power Supply

Type: External brick

Display voltage: DC 12V±5%

Input (line) voltage: 100-240 VAC, 50-60 Hz

 Environment

Operating Temp.

0～50°C

Operating RH

20%～80%

Storage Temp.

-20～60°C

Storage RH

10%～90%

 LED Back Light Life (Typ.)

≥30,000 Hours

 Weight（N.W/G.W）

6.5Kg(1pcs)/14.5Kg(2 pcs in one package)

 Package dimensions

650*195*435(mm)(2 pcs in one package)

 Power Consumption

Standby Power: ≤1.5W / Operating Power: ≤30W

 Mount Interface

 1.VESA 75mm and 100mm

 2.Mount bracket, horizontal or vertical mount

 OSD Control

Buttons

 AUTO,+,POWER,-,MENU

Function

Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset

 Agency approvals

 CCC, UL, FCC, CE, CB, RoHS

 Regular Warranty

1 year





Applications:

Retail

Gaming

Kiosk

Self-service

Finance

Transit

Conference

Education

Healthcare

Public service

E-commerce

Hotels

Restaurants







Support and Services:

PCAP Touch Monitor provides the following technical support and services:

  • 24/7 technical support
  • Onsite installation and training
  • Software and hardware maintenance
  • Warranty repair and replacement
  • Application development and integration






Advantages of PCAP Touch Monitor:

1. High sensitivity and accuracy: PCAP touch monitors offer excellent touch sensitivity, allowing for precise touch input even with a light touch.

2. Multi-touch support: PCAP touch monitors can support multiple simultaneous touch inputs, enabling advanced gestures and providing a more intuitive user experience.

3. Durability: PCAP touch monitors are built with a robust, chemically-strengthened glass surface that is highly resistant to scratches, wear, and damage.

4. Optical clarity: The glass surface of a PCAP touch monitor provides excellent optical clarity, allowing for high-quality image reproduction.

5. Slim and lightweight design: PCAP touch monitors typically have a slim and lightweight profile, which makes them easy to integrate into various systems and installations.





FAQ:

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer founded in 2006, located in Shenzhen, China.



2. What’s your MOQ for the PCAP touch monitor?

Our minimum order quantity is 1pc only.



3. What is your warranty period for the PCAP touch monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
