17 Inch Digital PCAP Touch Monitor Windows / Android / Linux Operating System

17 Inch Digital PCAP Touch Monitor Windows / Android / Linux Operating System
17 Inch Digital PCAP Touch Monitor Windows / Android / Linux Operating System 17 Inch Digital PCAP Touch Monitor Windows / Android / Linux Operating System 17 Inch Digital PCAP Touch Monitor Windows / Android / Linux Operating System 17 Inch Digital PCAP Touch Monitor Windows / Android / Linux Operating System 17 Inch Digital PCAP Touch Monitor Windows / Android / Linux Operating System
Place of OriginShenzhen, China
Brand NameKeeTouch
CertificationCCC, UL, FCC, CE, CB, RoHS
Model NumberKOT-0170U-CA4P
Minimum Order Quantity1piece
PriceNegotiable
Packaging DetailsCarton
Delivery Time7-15 work days
Payment TermsT/T, L/C, Western Union
Supply Ability10000 Pieces per Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product NamePCAP Touch MonitorResolution1280*1024
Operating SystemWindows/Android/LinuxTouch InterfaceUSB
Display Type5:4 Ratio 17" TFT-LCDSupport Colors16.7M
Active Area337.9*270.3(mm)Screen Size17‘’
High Light

Digital PCAP Touch Monitor

,

Linux PCAP Touch Monitor

,

PCAP 10 Touch Digital Monitor

Leave a Message
Product Description


Product Description:

Digital PCAP Touch Monitor Windows / Android / Linux Operating System


PCAP Touch Monitor is a multi-touch digital monitor with interactive display capabilities. It is designed with the latest 10-point multi-touch technology and 178° wide viewing angle to provide an optimal user experience. It offers an excellent resolution of 1280*1024 and is compatible with the Windows, Android and Linux operating systems. The touch interface is enabled by a USB connection and provides a reliable and smooth multi-touch experience. With its innovative design, PCAP Touch Monitor is a perfect solution for any interactive display needs.





Technical Parameters:

Complete Machine

Model No.

KOT-0170U-CA4P

Series

OT

Display Type

5:4 Ratio 17" TFT-LCD

Active Area

337.9*270.3(mm)

Monitor Dimensions (W*H*D)

378.9*313.3*47.3(mm)

Suggested Resolution

1280*1024 @ 60Hz

Support Colors

16.7M

Brightness (Typ.)

Pure LCD Panel

250cd/m²

With Touch Monitor

212cd/m²

Response Time (Typ.)

5ms

Viewing Angle(Typ.at CR10)

Horizontal(left/right)

85°/85°

Vertical(up/down)

80°/80°

Contrast Ratio (Typ.)

1000:1

Video Input

VGA/DVI

Frequency (H/V)

37.980KHz / 6075Hz



Power Supply

Type: External brick

Display voltage: DC 12V±5%

Input (line) voltage: 100-240 VAC, 50-60 Hz





Environment

Operating Temp.

050°C

Operating RH

20%80%

Storage Temp.

-2060°C

Storage RH

10%90%

LED Back Light Life (Typ.)

≥30,000 Hours

Weight N.W/G.W

4.1Kg(1pcs)/9.85Kg(2pcs in one package)

Package dimensions

466*185*403(mm)(2pcs in one package)

Power Consumption

Standby Power: ≤1.5W / Operating Power: ≤20W

Mount Interface

1.VESA 75mm and 100mm

2.Mount bracket, horizontal or vertical mount

OSD Control

Buttons

AUTO, +,POWER,-,MENU

Function

Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset

Agency approvals

CCC, UL, FCC, CE, CB, RoHS

Regular Warranty

1 year



Touch Screen

Touch Type

17" Riot capacitive touch screens

Touch input

USB

Response Time

≤10ms

Hardness

6H

Light Transmittance

≥85%

Support System

XP,WIN7,WIN8,WIN10,Linux,Android

Active Area

340.92*273.34(mm)

Thickness

3.9±0.3(mm)

Touch Test

≥50,000,000 times

Input Voltage

DC 5V±5%




Applications:

The KeeTouch Touch Screen Monitor is perfect for a wide range of applications. Whether used as an interactive kiosk in a retail store, an educational tool in a classroom, or as a digital signage solution, the KeeTouch PCAP Touch Screen Monitor is the optimal choice. With its 10-point multi-touch capability and intuitive user interface, it is sure to provide a superior user experience.








FAQ:

1. What is your warranty period for the PCAP touch monitor?

Our standard warranty is 12 months for all products, with an optional extension to 2-3 years.


2. What is your payment method?

We can accept T/T, Western Union, Paypal, Credit card, and Alipay.(L/C can be negotiable.)


3.Do you have stock?

Yes, we have a large quantity of stock for our regular models.
