OEM Widescreen PCAP Touch Screen Monitor 15.6 Inch With Multi Touch Panel
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Active Area | 344.16*193.59(mm) | Contrast Ratio (Typ.) | 500:1 |
|---|---|---|---|
| Video Input | VGA/DVI | Support Colors | 16.2M |
| Response Time | 8s | Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤15W |
| Regular Warranty | 1 Year | Product Name | PCAP Touch Monitor |
| Brightness | 400cd/㎡ |
Product Description
OEM Widescreen PCAP Touch Screen Monitor 15.6 Inch With Multi Touch Panel
PCAP Touch Monitor Description
With an anti-vandal, waterproof, 10 points touch screen and Full HD 1080P resolution, this PCAP touch monitor deliver crystal-clear viewing experience and accurate touch response. They are compatible with Operating systems XP, WIN7, WIN8, WIN10, Linux and Android. Also the regular sizes 8 inch, 10.1 inch, 10.4 inch, 12.1 inch, 15 inch, 15.6 inch, 17 inch, 18.5 inch, 19 inch, 21.5 inch, 23inch, 23.8 inch, 27 inch, 32 inch, 43 inch all are in stock, if you need other sizes, they can be customized.
PCAP Touch Monitor Specifications
Complete Machine | ||
Model No. | KOT-0156U-CA4P (P/N:KOT-156P-006) | |
Series | ||
Display Type | 16:9 Ratio 15.6" TFT-LCD | |
Active Area | 344.16*193.59(mm) | |
Monitor Dimensions (W*H*D) | 382*234*46.1(mm) | |
Suggested Resolution | 1920*1080 @ 60Hz | |
Support Colors | 16.2M | |
Brightness (Typ.) | Pure LCD Panel | 400cd/㎡ |
With Touch Monitor | 340cd/㎡ | |
Response Time (Typ.) | 8ms | |
Viewing Angle(Typ.at CR＞10)） | Horizontal(left/right) | 70°/70° |
Vertical(up/down) | 60°/60° | |
Contrast Ratio (Typ.) | 500:1 | |
Video Input | VGA/DVI | |
Frequency (H/V) | 37.9～80KHz / 60～76Hz | |
Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz | |
Environment | Operating Temp. | -10～70°C |
Operating RH | 8%～95% | |
Storage Temp. | -20～70°C | |
Storage RH | 5%～95% | |
MTBF | ≥50,000 Hours | |
LED Back Light Life (Typ.) | ≥50,000 Hours | |
Weight（N.W/G.W） | 2.7Kg(1pcs)/6.5Kg(2pcs in one package) | |
Package dimensions | 468*150*323(mm)(2pcs in one package) | |
Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤15W | |
Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
CCC, ETL, FCC, CE, CB, RoHS | ||
Regular Warranty | 1 year | |
Touch Screen | |
Touch Type | 15.6" Riot Capacitive touch screens |
Touch input | USB |
Response Time | ≤10ms |
Hardness | 7H |
Light Transmittance | ≥85% |
Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
Active Area | 345.2*194.5(mm) |
Thickness | 4.3±0.2(mm) |
Touch Test | ≥50,000,000 times |
Input Voltage | DC 5V±5% |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
Our Advantages
1) Price:
With the experience of 18+ years in the display industry, we already accumulate many leading suppliers for raw materials, which help us save the cost effectively and support our clients with a very competitive price.
2) Monthly capacity
More than 30,000 pcs
3) Quality:
Our products are certified with CE, UL, CB, BIS, ISO 14001, ISO 9001. etc. they are all go through strict and comprehensive quality management system test, which enable us to control every production aspect and ensure the reliable and good performance of products from the very beginning to the finished process.
Applications
Our PCAP touch monitors are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer founded in 2006, located in Shenzhen, China.
2. What’s your MOQ for the PCAP touch monitor?
Our minimum order quantity is 1pc only.
3.Do you have stock for PCAP touch monitors?
Yes, we have a large quantity of stock for our regular model products.
4. Can you produce the PCAP touch monitor according to the customer's requirements?
Sure, with 40+ Professional R&D engineers, OEM and ODM are welcomed.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Credit card and Alipay. ( L/C can be negotiable.
