Pure Flat Design 23.8 Inch PCAP Touch Monitor For Self Service Kiosks
| Place of Origin | Shenzhen, China |
|---|---|
| Brand Name | KeeTouch |
| Certification | FCC, CE, CB, RoHS, UL, CCC |
| Model Number | KOT-238P-005（KOT-0240U-CA2P） |
| Minimum Order Quantity | 1piece |
| Price | Negotiable |
Packaging Details | 2pcs in one package |
| Delivery Time | 7-15 work days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 10000 Pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Display Voltage | DC 12V±5% | Input (line) Voltage | 100-240 VAC, 50-60 Hz |
|---|---|---|---|
| Operating Temp | 0～50°C | Storage Temp | -20～60°C |
| Contrast Ratio (Typ.) | 3000:1(Typ.)/1800:1(Min.) | LED Back Light Life (Typ.) | ≥30,000 Hours |
| Hardness | 6H | Video Input | VGA/DVI/HDMI |
| Light Transmittance | ≥85% | Product Name | PCAP Touch Monitor |
| High Light | 23.8 Inch PCAP Touch Monitor,Kiosk PCAP Touch Monitor,Self Service Kiosk Touch Monitor | ||
Product Description
23.8 Inch PCAP Touch Monitor Pure Flat Design For Self-Service Kiosks
This PCAP touch monitor is anti-vandal and IP65 front frame waterproof , with good touch experience and high-definition visual enjoyment. With pure flat, the PCAP touch monitor is very sleek and attractive. The VGA, DVI, HDMI and USB interfaces for use and it supports operating systems: XP, WIN7, WIN8, WIN10, Linux, Android.According to your requirements, other sizes (7’’-43’’) are for your option.
PCAP Touch Monitor Specifications
Complete Machine | ||
Model No. | KOT-0240U-CA2P (P/N:KOT-238P-005) | |
Series | OT | |
Display Type | 16:9 Ratio 23.8" TFT-LCD | |
Active Area | 527.04(H) x 296.46(V)(mm) | |
Monitor Dimensions (W*H*D) | 580.5*350*48.7(mm) | |
Suggested Resolution | 1920*1080 @ 60Hz | |
Support Colors | 16.7M | |
Brightness (Typ.) | Pure LCD Panel | 250cd/m² |
With Touch Monitor | 212cd/m² | |
Response Time (Typ.) | 12ms | |
Viewing Angle(Typ.at CR＞10)） | Horizontal(left/right) | 89°/89°(Typ)/ 75°/75°(Min.) |
Vertical(up/down) | 89°/89°(Typ)/ 75°/75°(Min.) | |
Contrast Ratio (Typ.) | 3000:1(Typ.)/1800:1(Min.) | |
Video Input | VGA/DVI/HDMI | |
Frequency (H/V) | 37.9～80KHz / 60～75Hz | |
Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz | |
Environment | Operating Temp. | 0～50°C |
Operating RH | 20%～80% | |
Storage Temp. | -20～60°C | |
Storage RH | 10%～90% | |
MTBF | ≥30,000 Hours | |
LED Back Light Life (Typ.) | ≥30,000 Hours | |
Weight（N.W/G.W） | 6.5Kg(1pcs)/14.5Kg (2 pcs in one package) | |
Package dimensions | 650*195*435(mm) (2 pcs in one package) | |
Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤30W | |
Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness,Contrast Ratio, Auto-adjust, Phase,Clock, H/V Location,Languages, Function, Reset | |
Regular Warranty | 1 year | |
Touch Screen | |
Touch Type | 23.8" Capacitive touch screens |
Touch input | USB |
Hardness | 6H |
Light Transmittance | ≥85% |
Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
Active Area | 528*297.5(mm) |
Thickness | 4.3±0.2(mm) |
Touch Test | ≥50,000,000 次 |
Input Voltage | DC 5V±5% |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Advantages of PCAP Touch Monitor
1.High sensitivity and accuracy: PCAP touch monitors offer excellent touch sensitivity, allowing for precise touch input even with a light touch.
2.Multi-touch support: PCAP touch monitors can support multiple simultaneous touch inputs, enabling advanced gestures and providing a more intuitive user experience.
3.Durability: PCAP touch monitors are built with a robust, chemically-strengthened glass surface that is highly resistant to scratches, wear, and damage.
4.Optical clarity: The glass surface of a PCAP touch monitor provides excellent optical clarity, allowing for high-quality image reproduction.
5.Slim and lightweight design: PCAP touch monitors typically have a slim and lightweight profile, which makes them easy to integrate into various systems and installations.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer founded in 2006, located in Shenzhen, China.
2. What’s your MOQ for the PCAP Touch Monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the PCAP Touch Monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. What is your payment method?
We can accept T/T, Western Union, Paypal, Credit card, and Alipay.(L/C can be negotiable.)
5. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk production.
