Panel Mounted PCAP Touch Screen Monitor 21.5 Inch Full HD LCD Monitors
| Place of Origin | Shenzhen, China |
|---|---|
| Brand Name | KeeTouch |
| Certification | FCC, CE, CB, RoHS, UL, CCC |
| Model Number | KOT-215P-015(KOT-0215U-CA4P) |
| Minimum Order Quantity | 1piece |
| Price | Negotiable |
Packaging Details | 1pc in one package |
| Delivery Time | 7-15 work days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 10000 Pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Series | OT | Suggested Resolution | 1920*1080 @ 60Hz |
|---|---|---|---|
| Brightness | 250cd/m² | Video Input | VGA/DVI |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android | Response Time | 5s |
| Operating RH | 20%～80% | Thickness | 4.3±0.3(mm) |
| Input Voltage | DC 5V±5% | Product Name | PCAP Touch Monitor |
| Warranty | One Year |
Product Description
Panel Mounted PCAP Touch Screen Monitor 21.5 Inch Full HD LCD Monitors
They are using capacitive touch screen with 10 points touch, high transmission, 4.3mm thickness glass, more than 50,000,000 times touch test. Which deliver stable, drift-free operation for accurate touch response. Extensive connectivity HDMI, VGA, DVI provides access to a variety of equipment.
PCAP Touch Monitor Specifications
Complete Machine | ||
Model No. | KOT-0215U-CA4P (P/N:KOT-215P-011) | |
Series | OT | |
Display Type | 16:9 Ratio 21.5" TFT-LCD | |
Active Area | 478*270(mm) | |
Monitor Dimensions (W*H*D) | 516*311*40(mm) | |
Suggested Resolution | 1920x1080 @ 60Hz | |
Support Colors | 16.7M | |
Brightness (Typ.) | Pure LCD Panel | 250cd/m² |
With Touch Monitor | 212cd/m² | |
Viewing Angle(Typ.at CR＞10)） | Horizontal(left/right) | 85°/85° |
Vertical(up/down) | 80°/80° | |
Contrast Ratio (Typ.) | 1000:1 | |
Video Input | VGA/DVI/HDMI | |
Frequency (H/V) | 30～80KHz / 60～75Hz | |
Power Supply | Type: External brick Display voltage: DC 12V±5% | |
Environment | Operating Temp. | 0～50°C |
Operating RH | 20%～80% | |
Storage Temp. | -20～60°C | |
Storage RH | 10%～90% | |
MTBF | ≥30,000 Hours | |
LED Back Light Life (Typ.) | ≥30,000 Hours | |
Weight（N.W/G.W） | 5.6Kg(1pcs)/7.7Kg(1pcs in one package) | |
Package dimensions | 610*410*145(mm)(1pcs in one package) | |
Power Consumption | Standby Power: ≤1.5W /Operating Power: ≤30W | |
Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness,Contrast Ratio, Auto-adjust, Phase,Clock, H/V Location,Languages, Function, Reset | |
CCC, UL, FCC, CE, CB, RoHS | ||
Regular Warranty | 1 year | |
Touch Screen | |
Touch Type | 21.5" Capacitive touch screens |
Touch input | USB |
Response Time | ≤10ms |
Light Transmittance | ≥85% |
Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
Active Area | 477.6*269(mm) |
Thickness | 4.3±0.2(mm) |
Touch Test | ≥50,000,000 times |
Input Voltage | DC 5V±5% |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
Applications
KeeTouch PCAP Touch Monitors are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Our Advantages
Comprehensive product lines including PCAP/SAW/IR touch screen, Open frame touch monitors, all-in-one touch panel PCs, sheet metal cases. Monthly capacity is more than 30,000 pcs Products you received are inspected by rigorous reliability testing, such as burn-in test, anti-vibration test, high low temperature test to ensure quality.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a manufacrurer of industrial touch screen & touch monitor, founded in 2006, located in Shenzhen, China.
2. What's your MOQ for the PCAP touch monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the PCAP touch monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Do you have stock?
Yes, we have a large quantity of stock for our regular model products.
5.What are the shipping ways?
We will ship the goods according to customer’s requirement. For sample, normally by FedEx, DHL, UPS, TNT. For bulk order, by air or by sea.
