23.8 Inch PCAP Touch Monitor 16:9 Ratio With Full Viewing Angle

23.8 Inch PCAP Touch Monitor 16:9 Ratio With Full Viewing Angle
23.8 Inch PCAP Touch Monitor 16:9 Ratio With Full Viewing Angle 23.8 Inch PCAP Touch Monitor 16:9 Ratio With Full Viewing Angle 23.8 Inch PCAP Touch Monitor 16:9 Ratio With Full Viewing Angle 23.8 Inch PCAP Touch Monitor 16:9 Ratio With Full Viewing Angle 23.8 Inch PCAP Touch Monitor 16:9 Ratio With Full Viewing Angle
Place of OriginShenzhen, China
Brand NameKeeTouch
CertificationFCC, CE, CB, RoHS,UL,BIS
Model NumberKOT-0238U-CA4P(KOT-238P-002)
Minimum Order Quantity1piece
PriceNegotiable

Packaging

Details

Carton
Delivery Time7-15 work days
Payment TermsT/T, L/C, Western Union
Supply Ability10000 Pieces per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Response Time (Typ.)14msDisplay Type16:9 Ratio 23.8" TFT-LCD
Support Colors16.7MVideo InputVGA/HDMI
Contrast Ratio (Typ.)1000:1Operating RH20%~80%
Storage RH10%~90%Light Transmittance≥85%
Product NamePCAP Touch MonitorWarrantyOne Year
Leave a Message
Product Description


23.8 Inch PCAP Touch Monitor 16:9 Ratio With Full Viewing Angle


PCAP Touch Monitor Main Features

PCAP multi-touch screen, up to 10 points touch

Dust-proof and vandal-proof PCAP touch monitor with full viewing angle

High contrast ratio and high resolution PCAP touch monitor, high-quality image

Industrial grade, lasting touch, durable even in harsh environment

VGA/DHMI interfaces,USB for touch input

Multiple mounting options include VESA mount, horizontal vertical brackets mount

Support system: XP, WIN7, WIN8, WIN10, Linux, Android

Other sizes are optional (7''-43'')




PCAP Touch Monitor Specifications

Complete Machine

Model No.

KOT-0238U-CA4P (P/N:KOT-238P-002)

Series

OT

Display Type

16:9 Ratio 23.8" TFT-LCD

Active Area

528*297.5(mm)

Monitor Dimensions (W*H*D)

573.3*345.1*43(mm)

Suggested Resolution

1920*1080 @ 60Hz

Support Colors

16.7M

Brightness (Typ.)

Pure LCD Panel

250cd/m²

With Touch Monitor

215cd/m²

Response Time (Typ.)

14ms

Viewing Angle(Typ.at CR>10))

Horizontal(left/right)

89°/89°

Vertical(up/down)

89°/89°

Contrast Ratio (Typ.)

1000:1

Video Input

VGA/HDMI

Frequency (H/V)

30~82KHz / 50~75Hz



Power Supply

Type: External brick

Display voltage:DC 12V±5%

Input (line) voltage:100-240 VAC, 50-60 Hz





Environment

Operating Temp.

0~50°C

Operating RH

20%~80%

Storage Temp.

-20~60°C

Storage RH

10%~90%

MTBF

30,000 Hours

LED Back Light Life (Typ.)

30,000 Hours

Power Consumption

Standby Power: 2W / Operating Power: ≤27W

OSD Control

Buttons

AUTO,+,POWER,-,MENU

Function

Brightness,Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location,

Languages, Function, Reset

Agency approvals

CCC, UL, FCC, CE, CB, RoHS

Regular Warranty

1 year


Touch Screen

Touch Type

23.8" Capacitive touch screens

Touch input

USB

Response Time

≤10ms

Light Transmittance

≥87%

Support System

XP,WIN7,WIN8,WIN10,Linux,Android

Glass Thickness

3(mm)

Touch Test

≥50,000,000 times


NOTE :

① The display SPEC. are adjusted according to the selected LCD screen and touch screen

② The support system is adjusted according the specific system and version.





Applications

KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.





FAQ

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer founded in 2006, located in Shenzhen, China.


2. What's your MOQ for the PCAP Touch Monitor?

Our minimum order quantity is 1pc only.


3. What is your warranty period for the PCAP Touch Monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).


4. Can you produce the PCAP Touch Monitor according to the customer's requirements?

Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.


5. What is your payment method?

We can accept T/T, Western Union, Paypal,Credit card, and Alipay.(L/C can be negotiabl)


6. What is your delivery time?

3-5 work days for inventory orders, 7-15 business days for bulk production.
