1920x1080 Resolution Touch Display PCAP Touch Monitor 21.5 Inch

1920x1080 Resolution Touch Display PCAP Touch Monitor 21.5 Inch
1920x1080 Resolution Touch Display PCAP Touch Monitor 21.5 Inch 1920x1080 Resolution Touch Display PCAP Touch Monitor 21.5 Inch 1920x1080 Resolution Touch Display PCAP Touch Monitor 21.5 Inch 1920x1080 Resolution Touch Display PCAP Touch Monitor 21.5 Inch 1920x1080 Resolution Touch Display PCAP Touch Monitor 21.5 Inch
Place of OriginShenzhen, China
Brand NameKeeTouch
CertificationFCC, CE, CB, RoHS, UL, CCC
Model NumberKOT-215P-015(KOT-0215U-CA4P)
Minimum Order Quantity1piece
PriceNegotiable

Packaging

Details

2pcs in one package
Delivery Time7-15 work days
Payment TermsT/T, L/C, Western Union
Supply Ability10000 Pieces per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
SeriesOTSuggested Resolution1920*1080 @ 60Hz
Operating RH20%~80%Video InputVGA/DVI
Support SystemXP,WIN7,WIN8,WIN10,Linux,AndroidOperating Temp.0~50°C
Storage Temp.-20~60°CRegular Warranty1 Year
High Light

VGA Video Input PCAP Touch Monitor

,

PCAP Touch Monitor 1920x1080 Resolution

,

ODM 21.5 Inch Touch Monitor

Leave a Message
Product Description


21.5 Inch PCAP Touch Monitor 1920x1080 Resolution Touch Display



This 21.5 inch PCAP touch monitor comes with Projected Capacitive touch technology with high resolution and wide viewing angle. It is industrial grade PCAP touch monitor, durable and fashionable. Moreover, with high resolution and high contrast ratio, the touch monitor delivers high-quality image. According to customer’s individual requirements, OEM and ODM services can be offered.





PCAP Touch Monitor Specifications

 Complete Machine

 Model No.

 KOT-0215U-CA4P(P/N:KOT-215P-015)

 Series

 OT

 Display Type

16:9 Ratio 21.5" TFT-LCD

 Active Area

476.6*269(mm)

 Monitor Dimensions (W*H*D)

512.1*307.3*47(mm)

 Suggested Resolution

1920*1080 @ 60Hz

 Support Colors

16.7M

 Brightness (Typ.)

Pure LCD Panel

250cd/m²

With Touch Monitor

212cd/m²

 Response Time (Typ.)

5ms

 Viewing Angle(Typ.at CR>10))

 Horizontal(left/right)

 85°/85°

 Vertical(up/down)

 80°/80°

 Contrast Ratio (Typ.)

1000:1

 Video Input

VGA/DVI

 Frequency (H/V)

37.9~80KHz / 60~75Hz

 Power Supply

Type: External brick

Display voltage: DC 12V±5%

Input (line) voltage: 100-240 VAC, 50-60 Hz

 Environment

Operating Temp.

0~50°C

Operating RH

20%~80%

Storage Temp.

-20~60°C

Storage RH

10%~90%

 MTBF

≥30,000 Hours

 LED Back Light Life (Typ.)

≥30,000 Hours

 Weight(N.W/G.W)

5.6Kg(1pcs)/13.4Kg(2pcs in one package)

 Package dimensions

605*400*195(mm)(2pcs in one package)

 Power Consumption

Standby Power: ≤1.5W / Operating Power: ≤30W

 Mount Interface

 1.VESA 75mm and 100mm

 2.Mount bracket, horizontal or vertical mount

 OSD Control

Buttons

 AUTO,+,POWER,-,MENU

Function

Brightness,Contrast Ratio, Auto-adjust,Phase, Clock, H/V Location, Languages,

Function, Reset

 Agency approvals

 CCC, UL, FCC, CE, CB, RoHS

 Regular Warranty

1 year



Touch Screen

Touch Type

21.5" Capacitive touch screens

Touch input

USB

Response Time

≤10ms

Hardness

6H

Light Transmittance

≥85%

Support System

XP,WIN7,WIN8,WIN10,Linux,Android

Active Area

479.04*270.51(mm)

Thickness

4.3±0.3(mm)

Touch Test

≥50,000,000 times


NOTE :

① The display SPEC. are adjusted according to the selected LCD screen and touch screen

② The support system is adjusted according the specific system and version.




Applications

KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.





Why choose us?

1. We are a leading provider of industrial grade touch products and touch solutions, founded in 2006.

2. Our core competence is differentiated product customization. With over 40 professional R&D engineers, we can offer OEM and ODM services to meet customer’s individual requirements.

3. Our company has been approved by ISO9001 and ISO14001, and with the certifications CCC, UL, FCC, CE, CB, RoHS, etc. for the products.

4. Professional after-sales team at any time to provide services to customers.


FAQ

1. Can you produce the PCAP touch monitor according to the customer's requirements?

Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.


2. What is your payment method?

We can accept T/T, Western Union, Paypal, Credit card, and Alipay.(L/C can be negotiab)


3. What is your delivery time for the PCAP touch monitor?

3-5 work days for inventory orders, 7-15 business days for bulk production.
