IR 32 Inch Touch Screen Panel Explosion Proof With USB Connection OEM
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | IR Touch Screen | Operate System Support | Windows®7, Windows®8, Vista, XP, Mac® OS, Linux, Android |
|---|---|---|---|
| Response Time | ≤20ms | Power Supply | Signal USB Connection |
| Resolution | 4096 × 4096 | Linearity Deviation | ±1mm |
| Light Transmission | 92% With Cover Glass | Touch Durability | 60,000,000 Touch/cm² |
| High Light | IR 32 Inch Touch Screen Panel,OEM 32 Inch Touch Screen Panel,Explosion Proof 32 inch touch panel | ||
Product Description
32 Inch IR Touch Panel USB Connection Explosion Proof
IR Touch Panel Main Features
High stability, no drift due to time and environmental changes
Strong adaptability, free from current, voltage and static interference, suitable for some harsh environmental conditions (explosion-proof, dust-proof)
High light transmittance, no intermediate medium, up to 100%
The screen and touch have a long service life, and at the same time have the characteristics of high durability, scratch resistance, etc.
The control performance is good, the touch has no requirements on the use force, and there is no special demand for the touch body
IR Touch Panel Specifications
Size | 32 inch |
Housing | Aluminum |
Outside Dimensions | 742.5±1.5mm (L) ×430±1.5mm (W) ×9.4± 1.5mm(H) |
Active Area | 698.4±1.5mm (L) ×392.9±1.5mm (W) |
Aspect Ratio | 16:9 |
Drawing | Refer to Appendix 7 |
Touch Activation Force | No minimum touch pressure required |
Touch Durability | 60,000,000 touch/cm² |
Resolution | 4096 × 4096 |
Driver free | HID* compatible, up to 40 touch points |
Linearity Deviation | ±1mm |
Response Time | ≤20ms |
Light Transmission | 92% with cover glass |
Operate System Support | Windows®7, Windows®8, Vista, XP, Mac® OS, Linux, Android |
Power Supply | Signal USB Connection |
Low Power Consumption | Operating ≤1.4W, Stand by ≤250mW |
Temperature | Operating：0oC ~ 50o C |
Storage：-30oC ~ 60oC | |
Humidity | Operating：20% ~ 85% |
Storage： 0% ~ 95% | |
Certifications | FCC, CE, RoHS |
Applications
Widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. What is your delivery time for IR Touch Panel ?
3-5 work days for inventory orders, 7-15 business days for bulk production.
2. What package do you provide?
Our package usually is carton.
3. Do you have stock ?
Yes, we have a large quantity of stock for our IR Touch Panel .
4. What are the shipping ways?
We will ship the according to customer's requirement. For sample, normally by FedEx, DHL, UPS, TNT. For bulk order, by air or by sea.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
6. Do you give any discount of the IR Touch Panel ?
We will do utmost to support you with the competitive price, also good service will be offered.
