Infrared 21.5 Inch Touch Screen IP65 Waterproof For Outdoor
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | KeeTouch 21.5" Infrared Touch Screen | Operating Environment | Indoor And Outdoor |
|---|---|---|---|
| Waterproofness | IP65 | Interface | USB2.0 Full Speed |
| Humidity Storage | 0% ~ 95% | Humidity Operating | 20% ~ 85% |
| Temperature Storage | -30oC ~ 60oC | ||
| High Light | 21.5 Inch Touch Screen Waterproof,Infrared 21.5 Inch Touch Screen,USB2.0 Infrared Touch Screen | ||
Product Description
21.5 Inch Infrared Touch Screen IP65 Waterproof For Outdoor
Infrared Touch Monitor Main Features
This infrared touch screen comes with features as below: 16:9 aspect ratio, vandal-proof, IP65 surface water-proof, fast response, >92% high light transparency and four points touch. USB interface is provided for use. Strong adaptability, without interference of the current, voltage andstatic electricity, can be applied to some harsh environmental conditions. Various sizes are for your option (15''- 86'').
Infrared Touch Screen Specifications
Housing | Metal |
Outline Dimensions | 520±0.5mm(L) ×312±0.5mm(W) ×9±1mm(H) |
Active Area | 478±0.5mm(L) ×270±0.5mm(W) |
Aspect Ratio | 16:9 |
Net Weight | 1.9kg |
Glass | 3mm toughened glass, Transparence : >92% The light transmittance is decided by the glass Anti-dazzle glass can be customizable |
Drawing | Refer to Appendix 9 |
Touch Medium | Light-tight object. like Finger or touch pen |
Touch Activation Force | Non minimum activation force |
The depth Of The Touch | <5mm |
Resolution | 4096 × 4096 |
Response Time | ≤32ms |
The Size Of The Touch Medium | ≥Ø8mm |
Touch Lifetime | More than 50 million times |
Power requirements | Voltage DC ±5V, Minimum current 500mA |
Operating Current | <200mA |
Power Consumption | <2W The typical average power consumption<0.8W |
Electrostatic Discharge | Touch Discharge:4KV |
Air Discharge:8KV |
Temperature | operating:0oC ~ 50oC |
storage:-30oC ~ 60oC | |
Humidity | operating:20% ~ 85% |
storage: 0% ~ 95% | |
Light Resistance | Incandescent lamp (220V, 60W), above the touch screen plane 200 mm |
Interface | USB2.0 full speed (The standard type A connector) |
Waterproofness | IP65 (The front panel) |
Operating Environment | Indoor and outdoor |
Scanning | Auto full screen scanning |
Touch Trigger | Press, lift and drag |
Output | Coordinate |
Driver | Install the UPDD driver or PNP |
Firmware Upgrade | Firmware can be upgraded from USB |
Supported OS | Microsoft Windows 8 / 7 / XP / 2000 / VISTA Linux, Android(Determined by the firmware) |
Applications
Widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer, founded in 2006, located in Shenzhen, China.
2. What is your warranty period for the Infrared Touch Screen?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
3. Can you produce the Infrared Touch Screen according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
4. What package do you provide?
Our package usually is carton.
5. Do you have stock?
Yes, we have a large quantity of stock for our regular model products.
6. What are the shipping ways?
We will ship the goods according to customer's requirement. For sample, normally by FedEx, DHL, UPS, TNT. For bulk order, by air or by sea.
7. Do you give any discount for the Infrared Touch Screen?
We will do utmost to support you with the competitive price, also good service will be offered.
