Industrial Ir Touch Screen Monitor, 21.5 Inch Touch Monitor Vandal Proof
| Place of Origin | Shenzhen, China |
|---|---|
| Brand Name | KeeTouch |
| Certification | CCC, UL, FCC, CE, CB, RoHS |
| Model Number | KOT-215C-008(KOT-0215U-IR3P) |
| Minimum Order Quantity | 1 piece |
| Price | Negotiable |
Packaging Details | two pieces per carton |
| Delivery Time | 7-15 work days |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10000 Pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Infrared Touch Monitor | Display Type | 16:9 Ratio 21.5" TFT-LCD |
|---|---|---|---|
| Suggested Resolution | 1920*1080 @ 60Hz | Brightness | 250cd/m² |
| Video Input | VGA/DVI/HDMI | Viewing Angle | 178, 178 |
| Regular Warranty | 1 Year | Certificates | CCC, UL, FCC, CE, CB, RoHS |
| High Light | 21.5 Inch Ir Touch Screen Monitor,Vandal Proof Ir Touch Screen Monitor,Ir 21.5 Inch Touch Monitor | ||
Product Description
Industrial 21.5 Inch Infrared Touch Monitor Vandal-Proof 1920x1080
Infrared Touch Monitor Main Features
Infrared touch screen, accurate touch, fast response, 1- 40 points optional
Support embedded,wall-mounted,rack-mounted,desktop,VESA support
IP65 grade water-proof,dust-proof for front panel.
Compatible with various industrial systems/application
Aluminum alloy shell,good mechanical properties,better performance of heat dissipation
CCC, UL, FCC, CE, CB, RoHS certificate.
Support system: XP, WIN7, WIN8, Linux
Other sizes can be offered (7''- 43'')
Infrared Touch Monitor Specifications
Complete Machine | ||
Model No. | KOT-215C-008 (P/N:KOT-0215U-IR3P) | |
Series | ||
Display Type | 16:9 Ratio 21.5" TFT-LCD | |
Active Area | 476.64*268.11(mm) | |
Monitor Dimensions (W*H*D) | 520*312*45.8(mm) | |
Suggested Resolution | 1920*1080 @ 60Hz | |
Support Colors | 16.7M | |
Brightness (Typ.) | Pure LCD Panel | 250cd/m² |
With Touch Monitor | 225cd/m² | |
Viewing Angle(Typ.at CR＞10)） | Horizontal(left/right) | 89°/89° |
Vertical(up/down) | 89°/89° | |
Contrast Ratio (Typ.) | 1000:1 | |
Video Input | VGA/DVI/HDMI | |
Frequency (H/V) | 30～80KHz / 50～76Hz | |
Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60Hz | |
Environment | Operating Temp. | 0～50°C |
Operating RH | 20%～80% | |
Storage Temp. | -20～60°C | |
Storage RH | 10%～90% | |
MTBF | 30,000 Hours | |
LED Back Light Life (Typ.) | 30,000 Hours | |
Package dimensions | 605*195*400(mm) (2pcs in one package) | |
Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
Touch screen Type | Keetouch 21.5" IR touch screen | |
Touch System Interface | USB | |
CCC, UL, FCC, CE, CB, RoHS | ||
Regular Warranty | 1 year | |
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer founded in 2006, located in Shenzhen, China.
2. Do you have stock?
Yes, we have a large quantity of stock for our regular model products.
3. What is your warranty period for the infrared touch monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Do you support customization?
Yes. We are the manufacturer of Industrial Touch Screen and Touch Monitor. And have professional R&D Team, could customized the touch monitor according to your requirement.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Credit card, and Alipay.(L/C can be negotiable.)
6. How to ship to us from your factory?
Optional: Fedex/DHL/UPS/EMS, by air, by sea or to your China forwarder.
