XP / WIN7 / WIN8 15 Inch IR Touch Monitor 1024x768 Resolution For Kiosks
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Hardness | 7H | Light Transmittance | ≥90% |
|---|---|---|---|
| Support System | XP,WIN7,WIN8 | Response Time (Typ.) | 16ms |
| LED Back Light Life (Typ.) | ≥50,000 Hours | Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤20W |
| Mount Interface | VESA 75mm And 100mm | Regular Warranty | 1 Year |
| High Light | 1024x768 Resolution IR Touch Monitor,CCC IR Touch Monitor,15 Inch Infrared Touch Monitor | ||
Product Description
15 Inch IR Touch Monitor 1024x768 Resolution For Kiosks
Description of Infrared multi-touch monitor
This 15 inch IR touch monitor is highly durable and can withstand harsh environments. Infrared touch overlay monitor come with high durability, high accuracy, and multi-touch support. Besides, IR touch monitors are compatible with a wide range of operating systems and can be easily calibrated for accurate touch input detection. Also, with over 40 R&D engineers, customized services can be offered to meet customer’s individual requirements.
Infrared Touch Monitor Specifications
Complete Machine | ||
Model No. | KOT-0150U-IR3W (P/N:KOT-150W-018) | |
Series | OT | |
Display Type | 4:3 Ratio 15" TFT-LCD | |
Active Area | 304.128*228.096(mm) | |
Monitor Dimensions (W*H*D) | 351*275*55(mm) | |
Suggested Resolution | 1024*768 @ 60Hz | |
Support Colors | 16.2M | |
Brightness (Typ.) | Pure LCD Panel | 420cd/m2 |
With Touch Monitor | 378cd/m2 | |
Response Time (Typ.) | 16ms | |
Viewing Angle(Typ.at CR＞10)） | 80°/80° | |
80°/80° | ||
Contrast Ratio (Typ.) | 1000:1 | |
Video Input | VGA/DVI | |
Frequency (H/V) | 37.8～68.4KHz / 50～76Hz | |
Power Supply | Type: External brick Display voltage: DC 12V±5% | |
Environment | Operating Temp. | 0～50°C |
Operating RH | 20%～80% | |
Storage Temp. | -20～60°C | |
Storage RH | 10%～90% | |
MTBF | ≥50,000 Hours | |
LED Back Light Life (Typ.) | ≥50,000 Hours | |
Weight（N.W/G.W） | 3Kg(1pcs)/6.7Kg(2pcs in one package) | |
Package dimensions | 429*183*356(mm)(2pcs in one package) | |
Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤20W | |
Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
CCC, ETL, FCC, CE, CB, RoHS | ||
Regular Warranty | 1 year | |
Touch Screen | |
Touch Type | 15" Infrared touch screen |
Touch input | USB |
Response Time | ≤10ms |
Hardness | 7H |
Light Transmittance | ≥90% |
Support System | XP,WIN7,WIN8 |
Active Area | 306*230(mm) |
Thickness | 9±1(mm) |
Touch Test | 50,000,000 times |
Input Voltage | 5V |
Infrared interactive display Applications
Infrared touch monitor for industrial control are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Why choose us?
1. Quality products: All our products have passed strict quality inspection by the quality department before shipment.
2. Competitive pricing: With a strong supply chain, our products’ prices are very competitive.
3. Timely delivery: We have raw materials in stock all year round, the goods can be produced and sent out quickly.
4. Responsive Customer Service: Professional after-sales team at any time to provide services to customers.
FAQ
1. What package do you provide for the IR Touch Monitor?
Our package usually is carton.
2. Do you have stock?
Yes, we have a large quantity of stock for our regular model products.
3. What are the shipping ways?
We will ship the goods according to customer’s requirement. For sample, normally by FedEx, DHL, UPS, TNT. For bulk order, by air or by sea.
4. Do you give any discount for the Infrared touch monitor with adjustable stand?
We will do utmost to support you with the competitive price, also good service will be offered.
