4000:1 High Contrast Ratio 32 Inch Touch Monitor High Brightness

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xSeries | OT | Display Type | 16:9 Ratio 32" TFT-LCD |
---|---|---|---|
Suggested Resolution | 1920x1080 @ 60Hz | Operating Temp. | 0~50°C |
Operating RH | 20%~80% | Storage Temp. | -20~60°C |
Storage RH | 10%~90% | Regular Warranty | 1 Year |
High Light | Vandal Proof 32 Inch Touch Monitor,IP65 32 Inch Touch Monitor,TFT LCD High Brightness Touch Monitor |
32 Inch High Brightness Touch Monitor 4000:1 High Contrast Ratio
High Brightness Touch Monitor Main Features
This high brightness touch monitor comes with anti-glare, vandal-proof and IP65 waterproof functions, full viewing angle, high contrast ratio, delivering high quality image with super touch Experience. It provides VGA & DVI & HDMI interfaces, also USB for touch input. With over 40 engineers, OEM and ODM services are offered. Besides, other sizes (7''-43'') are available.
High Brightness Touch Monitor Specifications
Complete Machine | ||
Model No. | KOT-0320U-CA4PH(P/N:KOT-320P-025) | |
Series | OT | |
Display Type | 16:9 Ratio 32" TFT-LCD | |
Active Area | 698.4*392.85 (mm) | |
Monitor Dimensions (W*H*D) | 780*474*84.2(mm) | |
Suggested Resolution | 1920x1080 @ 60Hz | |
Support Colors | 16.7M | |
Brightness (Typ.) | Pure LCD Panel | 1000cd/m² , 1500cd/m² , 2000cd/m² |
With Touch Monitor | 850cd/m² , 1250cd/m² , 1650cd/m² | |
Response Time (Typ.) | 6.5ms | |
Viewing Angle(Typ.at CR>10)) | Horizontal(left/right) | 89°/89° |
Vertical(up/down) | 89°/89° | |
Contrast Ratio (Typ.) | 4000:1(Typ.)/3000:1(Min.) | |
Video Input | VGADVIHDMI | |
Frequency (H/V) | 60~73KHz / 47~63Hz | |
Power Supply | Type: External brick Display voltage: DC 24V/ 10A | |
Environment | Operating Temp. | 0~50°C |
Operating RH | 20%~80% | |
Storage Temp. | -20~60°C | |
Storage RH | 10%~90% | |
MTBF | 30,000 Hours | |
LED Back Light Life (Typ.) | 30,000 Hours | |
Mount Interface | Mount bracket, horizontal or vertical mount | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
CCC, UL, FCC, CE, CB, RoHS | ||
Regular Warranty | 1 year |
Touch Screen | |
Touch Type | 32" Capacitive touch screens |
Touch input | USB |
Hardness | ≥6H |
Light Transmittance | ≥83% |
Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
Touch Test | ≥50,000,000 times |
Input Voltage | DC 5V±5% |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
Products Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer, founded in 2006, located in Shenzhen, China.
2. What’s your MOQ for the high brightness touch monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the high brightness touch monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. What is your payment method?
We can accept T/T, Western Union, Paypal, Credit card, and Alipay.(L/C can be negotiable.)
5. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk production.
