Outdoor 8 Inch Touch Screen Monitor 1024×768 For Vending Machines

Outdoor 8 Inch Touch Screen Monitor 1024×768 For Vending Machines
Outdoor 8 Inch Touch Screen Monitor 1024×768 For Vending Machines Outdoor 8 Inch Touch Screen Monitor 1024×768 For Vending Machines Outdoor 8 Inch Touch Screen Monitor 1024×768 For Vending Machines Outdoor 8 Inch Touch Screen Monitor 1024×768 For Vending Machines Outdoor 8 Inch Touch Screen Monitor 1024×768 For Vending Machines Outdoor 8 Inch Touch Screen Monitor 1024×768 For Vending Machines
Place of OriginShenzhen，China
Brand NameKeeTouch
CertificationCCC, UL, FCC, CE, CB, RoHS
Model NumberKOT-0080U-CA4PH
Minimum Order Quantity1 piece
PriceNegotiable
Packaging Detailscarton
Delivery Time7-15 work days
Payment TermsL/C, T/T, Western Union
Supply Ability2000 Pieces per Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
SeriesOTSuggested Resolution1024*768 @ 60Hz
Contrast Ratio (1000:1Video InputVGA/HDMI/DVI
Active Area163*122.5(mm)Brightness-Pure LCD Panel≥1000cd/m²
Brightness-With Touch Monitor≥850cd/m²Product NameHigh Brightness Touch Monitor
High Light

8 Inch Touch Screen Monitor 1024×768

,

Outdoor 8 inch touch screen monitor

,

Vending Machines 8 inch touch monitor

Leave a Message
Product Description


8 Inch High Brightness Touch Monitor For Outdoor Kiosks Vending Machines


High Brightness Touch Monitor Main Features


  • PCAP multi touch screen, accurate touch and fast-response

  • High contrast, high resolution touch monitor with full viewing angle

  • High brightness sunlight readable, 1000 - 2000 nits optional

  • Anti-glare, anti-vandal and dust-proof functions

  • Pure flat high brightness touch monitor with IP65 front side waterproof function

  • HDMI+VGA+DVI interfaces,USB for touch

  • Operation system: XP,WIN7,WIN8,WIN10, Linux, Android

  • Other sizes can be offered (8''- 43'')




High Brightness Touch Monitor Specifications


 Complete Machine

 Model No.

 KOT-0080U-CA4PH (P/N:KOT-008C-005)

 Series

 OT

 Display Type

4:3 Ratio 8" TFT-LCD

 Active Area

163*122.5(mm)

 Monitor Dimensions (W*H*D)

 214*177*40.7(mm)

 Suggested Resolution

1024*768 @ 60Hz

 Support Colors

16.2M

 Brightness (Typ.)

Pure LCD Panel

≥1000cd/m2

With Touch Monitor

≥850cd/m2

 Response Time (Typ.)

16ms

 Viewing Angle(Typ.at CR＞10)）

 Horizontal(left/right)

 89°/89°

 Vertical(up/down)

 89°/89°

 Contrast Ratio (Typ.)

 1000:1

 Video Input

 VGA/HDMI

 Frequency (H/V)

 30～80KHz / 60～75Hz

 Power Supply

Type: External brick

Display voltage: DC 12V±5% 3.3A
Input (line) voltage: 100-240 VAC, 50-60 Hz

 Environment

Operating Temp.

-15～50°C

Operating RH

20%～80%

Storage Temp.

-20～60°C

Storage RH

10%～90%

 MTBF

≥ 30,000 Hours

 LED Back Light Life (Typ.)

≥ 30,000 Hours

 Power Consumption

Standby Power: ≤1.5W / Operating Power: ≤13W

 Mount Interface

 Mount bracket, horizontal or vertical mount

 OSD Control

Buttons

 AUTO,+,POWER,-,MENU

Function

Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset

 Agency approvals

 CCC, ETL, FCC, CE, CB, RoHS

 Regular Warranty

1 year



Touch Screen

Touch Type

8" capacitive touch screens

Touch input

USB

Response Time

≤10ms

Hardness

6H

Light Transmittance

>80%

Support System

Multi-Touch : WIN7、WIN8、WIN10

Single Touch : XP

Touch Test

≥ 50,000,000 次

Input Voltage

DC 5V±5%


NOTE :

① The display SPEC. are adjusted according to the selected LCD screen and touch screen

② The support system is adjusted according the specific system and version.




Applications



KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.



100




FAQ

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer since 2006, located in Shenzhen, China.



2. What’s your MOQ for the High Brightness Touch Monitor?

Our minimum order quantity is 1pc only.



3. What is your warranty period for the High Brightness Touch Monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).



4. Can you produce the High Brightness Touch Monitor according to the customer's requirements?

Sure, with 40+ Professional R & D engineers, OEM and ODM are offered.



5. What is your payment method?

We can accept T/T, Western Union, Paypal, Credit card, and Alipay.(L/C can be negotiable.)



6. What is your delivery time for the High Brightness Touch Monitor?

3-5 work days for inventory orders, 7-15 business days for bulk production.
