Sunlight Readable High Brightness Touch Monitor Screen 27" For Banking ATMs

Sunlight Readable High Brightness Touch Monitor Screen 27
Sunlight Readable High Brightness Touch Monitor Screen 27 Sunlight Readable High Brightness Touch Monitor Screen 27 Sunlight Readable High Brightness Touch Monitor Screen 27 Sunlight Readable High Brightness Touch Monitor Screen 27 Sunlight Readable High Brightness Touch Monitor Screen 27
Place of OriginShenzhen, China
Brand NameKeeTouch
CertificationCCC, UL, FCC, CE, CB, RoHS
Model NumberKOT-0270U-CA4PH
Minimum Order Quantity1 piece
PriceNegotiable

Packaging

Details

carton
Delivery Time7-15 work days
Payment TermsL/C, T/T, Western Union
Supply Ability10000 Pieces per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
LED Back Light Life30,000 HoursSuggested Resolution1920*1080 @ 60Hz
Contrast Ratio (3000:1Video InputVGA/HDMI
Active Area597.6*336.15(mm)Brightness-Pure LCD Panel1000cd/m²
Brightness-With Touch Monitor850cd/m²Viewing Angle(Typ.at CR>10))Horizontal(left/right) 89°/89°  Vertical(up/down) 89°/89°
MTBF≥ 30,000 HoursAgency ApprovalsCCC, UL, FCC, CE, CB, RoHS
Touch InputUSBSupport SystemMulti-Touch : WIN7,WIN8,WIN10 Single Touch : XP
Sample Leadtime7-14 Days

High Light

sunlight Readable High Brightness Touch Monitor

,

ATMs High Brightness Touch Monitor

,

27" sunlight readable touch screen monitor

Leave a Message
Product Description


27" Inch High Brightness Touch Monitor Daylight Readable For Banking ATMs


High Brightness Touch Monitor Main Features

Multi-points PCAP touch panel, high sensitive and fast-response

Anti-glare,vandal-proof and dust-proof, IP65 surface waterproof function

High brightness sunlight readable,1000 - 2000 nits optional

Support Resistive touch, SAW touch , IR touch, Capacitive touch.

Compatible with various industrial systems/application.




High Brightness Touch Monitor Specifications

 Complete Machine

 Model No.

 KOT-0270U-CA4PH (P/N:KOT-270P-005-01)

 Series

 OT

 Display Type

16:9 Ratio 27" TFT-LCD

 Monitor Dimensions (W*H*D)

655.9*394.4*87(mm)

 Suggested Resolution

1920*1080 @ 60Hz

 Brightness (Typ.)

Pure LCD Panel

1000cd/m²

With Touch Monitor

850cd/m²

 Response Time (Typ.)

12ms

 Viewing Angle(Typ.at CR>10))

 Horizontal(left/right)

 89°/89°

 Vertical(up/down)

 89°/89°

 Contrast Ratio (Typ.)

3000:1

 Video Input

VGA/HDMI

 Frequency (H/V)

30~80KHz / 50~76Hz

 Power Supply

Type: External brick

Display voltage:DC 24V 7A ±5%

Input (line) voltage: 100-240 VAC, 50-60 Hz

 Environment

Operating Temp.

0~50°C

Operating RH

20%~80%

Storage  Temp.

-20~60°C

Storage RH

10%~90%

 MTBF

30,000 Hours

 LED Back Light Life (Typ.)

30,000 Hours

 Power Consumption

Standby Power: 2.5W / Operating Power: ≤120W

Mount Interface

1.  VESA 75mm and 100mm

2.  Mount bracket, horizontal or vertical mount

 Weight(N.W/G.W)

12.5Kg/17.35Kg

 Package dimensions

80.5*23.3*55.3cm

 OSD Control

Buttons

 AUTO,+,POWER,-,MENU

Function

Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location,

Languages, Function, Reset

 Agency approvals

 CCC, UL, FCC, CE, CB, RoHS

 Touch System Interface

 USB

 Support System

 10 points in win7,Win xp 1 point

 Regular Warranty

1 year


NOTE :

① The display SPEC. are adjusted according to the selected LCD screen and touch screen

② The support system is adjusted according the specific system and version.





Applications

1. Business Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.

2. Financial Organizations: Banks, negotiable securities, funds, insurance companies;

3. Non-profit Organizations: Telecommunications, post offices, hospital, schools;

4. Entertainments: Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course.






Advantages of High Brightness Touch Monitor

1.Improved visibility: High-brightness PCAP touch monitors typically have a brightness level of 1000 nits or more, which makes them ideal for use in bright environments such as outdoor settings or areas with high ambient light.

2.Enhanced durability: PCAP touch monitors are known for their durability and resistance to scratches, abrasions, and vandalism. The touch screens are made of tempered glass, which is tough and resistant to impact damage.

3.Accurate touch response: PCAP touch screens are highly responsive and offer accurate touch detection, even when used with gloves or in wet conditions.

4.Multi-touch support: High-brightness PCAP touch monitors support multi-touch gestures, which means that users can interact with the screen using multiple fingers at once. This makes it easier to perform complex operations and to manipulate images or data on the screen.

Customizable: High-brightness PCAP touch monitors can be customized to meet specific requirements, such as different screen sizes, aspect ratios, and brightness levels.




FAQ

1. What's your MOQ?

Our minimum order quantity is 1pc only.


2. What is your warranty period?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).


3. What is your delivery time?

3-5 work days for inventory orders, 7-15 business days for bulk production.


4. What package do you provide?

Our package usually is carton.


5. Do you have stock?

Yes, we have a large quantity of stock for our regular model products.


6. Do you give any discount?

We will do utmost to support you with the competitive price, also good service will be offered.
