USB Multitouch PCAP Touch Screen 19 Inch For POS ATM Vending Kiosk
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Projected Capacitive Touch Screen | Touch IC | ILI2510 |
|---|---|---|---|
| Interface Type | USB | Number Of Touch Point | 1point Touch In XP,10 Points Touch In Win7,win8 OS |
| Input | Hand Writing Or Capacitive Pen | Thickness | 4.3±0.3mm |
| Response Time | 10s | Product Name | PCAP Touch Screen |
| High Light | Multitouch PCAP Touch Screen,ATM PCAP Touch Screen,POS Touch Screen 19 Inch | ||
Product Description
19 Inch PCAP Touch Screen USB Multitouch POS ATM Vending Kiosk
PCAP Touch Screen Main Features
- Adopt PCAP touch technology, up to 10 point multi-touch
- the PCAP Touch Screen has Fast response time ≦10ms, accurate touch, high optical penetration, free of drift
- With tempered glass, vandal proof and dust proof
- The PCAP Touch Screen has High transparency, ≧85%, high clarity, high touch durability and long term stability
- USB interface for touch, support Windows XP, Win7, Win8 OS
- Other sizes are optional (7’’- 43’’)
PCAP Touch Screen Specifications
| Item | Contents |
| Type | Projected Capacitive Touch Screen |
| Size | 19 inch |
| Thickness | 4.3±0.3mm |
| Outline Dimension | 449.70*298.65±0.2mm |
| Active Area(L*W) | 411.50*259.90 |
| View Area | 409.50*257.40±0.3mm |
| ITO Glass thickness ITO | 1.10mm |
| Cover lens thickness | 3.00mm |
| Total | 4.30mm |
| Touch IC | ILI2510 |
| Interface Type | USB |
| Number of touch point | 1point touch in XP,10 points touch in win7,win8 OS |
| Input voltage | 5V |
| Response time | 10 ms |
| Pressure endurance value | <10g |
| Input | Hand writing or capacitive pen |
| Transmittance | ≥85% |
| Surface Hardness | ≥6H |
Applications
Widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
2. What’s your MOQ for the PCAP Touch Screen?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the PCAP Touch Screen?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Can you produce the PCAP Touch Screenaccording to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are offered.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
6. What is your delivery time for the PCAP Touch Screen?
3-5 work days for inventory orders, 7-15 business days for bulk production.
