Open Frame Infrared Touch Monitor 1280×1024 IP65 Water Proof

Open Frame Infrared Touch Monitor 1280×1024 IP65 Water Proof
Open Frame Infrared Touch Monitor 1280×1024 IP65 Water Proof Open Frame Infrared Touch Monitor 1280×1024 IP65 Water Proof Open Frame Infrared Touch Monitor 1280×1024 IP65 Water Proof Open Frame Infrared Touch Monitor 1280×1024 IP65 Water Proof Open Frame Infrared Touch Monitor 1280×1024 IP65 Water Proof
Place of OriginShenzhen,China
Brand NameKeeTouch
CertificationCCC, UL, FCC, CE, CB, RoHS
Model NumberKOT-0170U-IR3W(KOT-170P-021)
Minimum Order Quantity1 piece
PriceNegotiable
Packaging DetailsCarton
Delivery Time7-15 work days
Payment TermsL/C, T/T, Western Union
Supply Ability10000 Pieces per Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name17'' Infrared Touch MonitorDisplay Type5:4 Ratio 17" TFT-LCD, LED Backlight
Suggested Resolution1280×1024 @60HzViewing Angle85/85, 80/80
Video InputVGA/DVITouch InputUSB
Brightness250 cd/m²CertificatesCCC, UL, FCC, CE, CB, RoHS
High Light

Infrared Touch Monitor 1280×1024

,

Infrared Touch Monitor Dust Proof

,

IP65 Open Frame Touch Monitor

Leave a Message
Product Description

Industrial 17 Inch Infrared Monitor 1280*1024 Open Frame Touch Monitor



Infrared Touch Monitor Main Features

  • Infrared multi touch panel, high quality touch experience

  • IP65 grade water-proof,dust-proof for front panel

  • Professional pure flat designed with IP65 front surface waterproof function

  • CCC, ETL, FCC, CE, CB, RoHS certificate

  • VGA+DVI interfaces,USB for touch

  • Multiple mounting options include VESA mount, horizontal vertical brackets mount

  • Support system: XP,WIN7,WIN8,WIN10, Linux, Android

  • Support Resistive touch, SAW touch , IR touch, Capacitive touch

Infrared Touch Monitor Specifications





Complete Machine
Model No.KOT-0170U-IR3W(KOT-170P-021)
SeriesOT
Display Type5:4 Ratio 17" TFT-LCD,LED backlight
Active Area337.3*270.3(mm)
Monitor Dimensions (W*H*D)381*313*52(mm)
Suggested Resolution1280*1024 @ 60Hz
Support Colors16.7M
Brightness (Typ.)Pure LCD Panel250cd/m2
With Touch Monitor135cd/m2
Response Time (Typ.)5ms
Viewing Angle(Typ.at CR>10))Horizontal(left/right)85°/85°
 Vertical(up/down)80°/80°
Contrast Ratio (Typ.)1000:1
Video InputVGA/DVI
Frequency (H/V)30~80KHz / 60~75Hz
Power SupplyType: External brick
Display voltage: DC 12V±5%
Input (line) voltage: 100-240 VAC, 50-60 Hz
EnvironmentOperating Temp.0~50°C
Operating RH20%~80%
Storage Temp.-20~60°C
Storage RH10%~90%
MTBF≥30,000 Hours
LED Back Light Life (Typ.)≥30,000 Hours
Power ConsumptionStandby Power: ≤1.5W / Operating Power: ≤20W
Mount Interface1.VESA 75mm and 100mm
2.Mount bracket, horizontal or vertical mount
OSD ControlButtonsAUTO,+,POWER,-,MENU
FunctionBrightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Agency approvalsCCC, UL, FCC, CE, CB, RoHS
Regular Warranty1 year

Touch Screen
Touch Type17" Infrared touch screen
Touch inputUSB
Response Time20ms
Hardness7H
Light Transmittance≥90%
Support SystemXP,WIN7,WIN8,WIN10,Linux,Android
Active Area339*271(mm)
Thickness9±1(mm)
Touch Test≥50,000,000 times
Input VoltageDC 5V±5%





Applications

KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.




Open Frame Infrared Touch Monitor 1280×1024 Dust Proof IP65 Grade Water Proof 1





FAQ



1.How to ship to us from your factory?

Optional: Fedex/DHL/UPS/EMS, by air, by sea or to your China forwarder.



2. Do you give any discount?

We will do utmost to support you with the competitive price, also good service will be offered.



3. Do you support customization?

Yes. We are the manufacturer of Industrial Touch Screen and Touch Monitor. And have professional R&D Team, could customized the touch monitor according to your requirement.



4. What is your payment method?

We can accept T/T, Western Union, Paypal, Credit card and Alipay. ( L/C can be negotiable. )



5. Do you have stock?

Yes, we have a large quantity of stock for our regular model products.
